Поз.
Артикул
Описание
5
POWER TAKE-OFF , DETERMINE VARIANT NUMBER FROM VEDOC
5
P.T.O.NA121-1B, DETERMINE VARIANT NUMBER FROM VEDOC
5
P.T.O. , FOR COMPONENT PARTS SEE SPARE PARTS LIST
5
P.T.O. , Replaced By: XVV65040616
11
HOUSING , Replaced By: A9452642301
11
HOUSING P.T.O., Replaced By: A9452601126
11
HOUSING P.T.O.
11
HOUSING P.T.O.
17
TYPE PLATE HOUSING,TOP
20
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
20
GASKET P.T.O. TO TRANSMISSION
23
BUSHING P.T.O. HOUSING
26
THREADED PIN TRANSMISSION CASE TO TRANSMISSION CASE
50
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
50
SPRING WASHER CAB FLOOR
53
HEXAGON NUT W FLANGE COVER TO P.T.O. CASE M12
53
NUT COVER TO FLANGE
56
GASKET P.T.O. TO TRANSMISSION
59
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
95
SEAL RING DRIVE SHAFT,INSIDE
97
SEAL RING DRIVE SHAFT,OUTSIDE
101
TRANSMISSION CASE COVER SHIFT CASE, FOR COMPONENT PARTS SEE SPARE PARTS LIST
101
TRANSMISSION CASE COVER , Replaced By: A3892604513
104
BALL BEARING
104
BALL BEARING
107
SPACER RING BEARING COVER,INSIDE,186372
110
LOCK RING BALL BEARING TO OUTPUT SHAFT
113
DRIVE SHAFT BOTTOM,186372
116
RETAINING RING BEARING TO DRIVE SHAFT
122
SHIFTING FORK P.T.O. CONTROL
125
PISTON P.T.O. CONTROL
128
SEAL RING PISTON
131
SEAL RING PISTON
142
GASKET SHIFTING CYLINDER TO CASE
164
SPRING SLIDING COLLAR
179
SNAP RING P.T.O. INDICATOR ACTUATION
182
SWITCH P.T.O. CONTROL
182
SWITCH , Replaced By: A0015455009
185
SEAL RING ON OIL PUMP HOUSING
