Поз.
Артикул
Описание
5
P.T.O. FOR BREAK-DOWN,SEE UNIT STANDARD VERSIONMODEL: 715.5
8
GASKET P.T.O. TO TRANSMISSION
11
SCREW P.T.O. TO TRANSMISSION M10 X 90
11
HEXALOBULAR BOLTM10X170
11
SCREW , Replaced By: N000000003888
11
SCREW P.T.O. TO TRANSMISSION M10 X 150
14
HOUSING LOWER PART
17
SCREWM 8X40
17
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
17
SCREW VALVE TO BRACKET M 8X55
20
SCREW. HEXAGON HEAD BOLT RADIATOR PROTECTION,BOTTOM
23
WASHER TRANSMISSION CASE TO TRANSMISSION CASE
26
EXPANSION PLUG HOUSING,BOTTOM
29
CYLINDRICAL PIN POWER CYLINDER TO SUPPORT
32
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
35
SEAL RING ON OIL PUMP HOUSING
38
SCREW PLUG HOUSING,BOTTOM,183596
41
HOUSING UPPER PART
44
PLUG P.T.O. HOUSING
47
HEADLESS SETSCREW HOUSING,TOP
50
TYPE PLATE HOUSING,TOP
53
INTERMEDIATE SHAFT WITH RETARDER
53
INTERMEDIATE SHAFT WITH RETARDER
53
INTERMEDIATE SHAFT LESS RETARDER
56
CYLINDR. ROLLER BEARING DRIVE SHAFT,FRONT
167
OIL PIPE OIL LINE TO TRANSMISSION
170
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
173
SCREW CLAMP MOUNTING M6 X 16
176
SCREW PLUG
179
SEALING RING. SEAL RING OIL DRAIN
182
MOUNTING PLATE ELECTRIC CABLE
182
BRACKET ELECTRIC CABLE, Replaced By: A9605462582
185
SCREWM 10X20
188
P.T.O. PARTS KIT
191
GASKET P.T.O. TO TRANSMISSION
194
SCREW P.T.O. TO TRANSMISSION M10 X 90
194
HEXALOBULAR BOLTM10X170
194
SCREW , Replaced By: N000000003888
194
SCREW P.T.O. TO TRANSMISSION M10 X 150
197
PLASTIC PIPE RISING PIPE 4X6 MM
200
DISTRIBUTOR HOSE WIDTH, 6 MM
203
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
203
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
206
HOLLOW SCREW LINE CONNECTION
209
SEAL RINGTO 001 431 72 14
