Поз.
Артикул
Описание
5
COVER SHIFT CASE,001875,5 K 90 GP003320,5 S 90 GP
5
COVER , Replaced By: A0002683105
11
SHAFT SHIFTING LOCK
14
PISTON SHIFTING LOCK
17
LOCK PISTON TO ROD
20
SEAL RING SHIFTING LOCK
23
SPACER WASHER SHIFTING SHAFT,BOTTOM
26
SPACER WASHER AS REQUIRED 0.50 MM
26
SPACER WASHER SHIFTING ROD, AS REQUIRED 0.20 MM,131010
26
SPACER WASHER , Replaced By: A6022640852
26
SPACER WASHER , Replaced By: A6022640852
29
SEAL RING SHIFTING SHAFT,BOTTOM
32
BUSHING SHIFTING SHAFT,BOTTOM
35
SEAL RING SHIFTING SHAFT,BOTTOM
38
SEAL RING CONTROL UNIT BRANCH-OFF
41
DETENT TRANSMISSION CASE
41
DETENT , Replaced By: A0002601873
47
LOCK PLATE SHIFT CASE
50
COVER SHIFTING LOCK,019226
56
PIN SHIFT CASE,BOTTOM
56
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002683974
59
SPRING SHIFT CASE
65
GASKET , Replaced By: A0002685180
65
GASKET SHIFT CASE,TOP AND BOTTOM
68
COVER SHIFT CASE,BOTTOM
74
NEEDLE BEARING REAR DRIVE SHAFT
74
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
77
BREATHER SHIFTING LOCK
95
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
95
SCREW FRONT AXLE REGULATING SOLENOID VALVE
95
SCREW , Replaced By: N000933008134
95
SCREW , Replaced By: N304017008027
95
SCREW VALVE TO BRACKET
98
SPRING WASHER , Replaced By: N000137008212
98
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
104
SCREW PLUG
104
SCREW PLUG TOP AND BOTTOM
107
PIN
110
EXPANSION PLUG HOUSING,BOTTOM
110
COVER , Replaced By: A0009971120
113
SLOTTED GATE
116
GASKET VALVE TO TRANSMISSION
116
GASKET , Replaced By: A0002685080
119
SCREW CLAMP TO BRACKET AND TO PIPE
122
SPRING WASHER , Replaced By: N000137008212
122
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
125
COVER LATERAL
128
GASKET , Replaced By: A0002685580
128
GASKET , Replaced By: A0002682180
128
GASKET LATERAL
131
SCREW BRACKET TO TAIL LAMP BRACKET
134
SPRING WASHER ALTERNATOR CONNECTION D+
149
SPRING SHIFTING LOCK,039559
152
PIN SHIFTING LOCK,039559
155
EXPANSION PLUG ROD END
161
BUSHING CRAWLER-GEAR/REVERSE-GEAR INTERLOCK,003528,5 S 90 GPA001871,5 K 90 GPA
161
BUSHING SHIFT CASE,TOP
164
SPRING SHIFT CASE
167
BEARING COVER SHIFTING DOME
167
BEARING COVER , Replaced By: A0002680634, +001N000906010000
167
BEARING COVER , Replaced By: A0002680034
170
BUSHING SHIFTING DOME,TOP
173
SEAL RING SHIFTING SHAFT
176
BOOT SHIFTING SHAFT
179
GASKET SHIFT CASE,TOP AND BOTTOM
182
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
182
SCREW , Replaced By: N000933008337
182
SCREW , Replaced By: A0099900101
185
SPRING WASHER , Replaced By: N000137008212
185
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
188
VALVE BREATHER
191
SCREW PLUG STABILIZER
194
GASKET , Replaced By: A0002686180
194
GASKET SHIFT CASE
197
SCREW , Replaced By: N304017010050
197
SCREW , Replaced By: N304014010004
197
SCREW , Replaced By: N000933010192
197
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
197
SCREW , Replaced By: N304017010055
197
SCREW CLUTCH TO FLYWHEEL
197
SCREW SHIFTING ROD TO SHIFT LEVER
197
SCREW SHIFT CASE TO TRANSMISSION M 10X105
197
SCREW BRACKET TO BELL HOUSING
200
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
PLUG 4/2-WAY VALVE,001875,5 K 90 GP003320,5 S 90 GP
999
PLUG , Replaced By: A0019972635
999
PLUG SHIFTING CYLINDER
