Поз.
Артикул
Описание
26
SHIFTING ROD SPLITTER BOX
29
SHIFTING FORK SPLITTER BOX
29
SHIFTING FORK , Replaced By: A0002653701
32
STUD , Replaced By: A0002650575
32
THREADED PIN ADDITIONAL GEAR CLUSTER
35
SLIDE SHIFTING FORK
35
SLIDE , Replaced By: A0002680849
38
DETENT SHIFTING ROD DETENT
38
LOCK SHIFTING ROD DETENT
41
SEAL RINGTO 006 997 00 72
44
PIN ADDITIONAL GEAR CLUSTER
44
PIN , Replaced By: A0009976010
47
SCREW PLUG
50
SEAL RING VALVE TO VALVE,K 025179
53
SHIFTING CYLINDER SPLITTER BOX
53
SHIFTING CYLINDER , Replaced By: A0002670519
56
SEAL RING
59
BOOT , Replaced By: A0002670697
59
BOOT SHIFTING SHAFT
62
PISTON , Replaced By: A0002670918
62
PISTON SHIFTING CYLINDER
62
PISTON SHIFTING CYLINDER
65
SEAL RING , Replaced By: A0002670997
65
BOOT SHIFTING CYLINDER
68
NUT , Replaced By: N910113016001
68
NUT CONSOLE TO SUPPORT
71
SHIFTING ROD ADDITIONAL GEAR CLUSTER
71
SHIFTING ROD , Replaced By: A0012653205, +001A0002658205, +002A0002650170
74
SHIFTING ROD ADDITIONAL GEAR CLUSTER
74
SHIFTING FORK , Replaced By: A0012658205
74
SHIFTING ROD ADDITIONAL GEAR CLUSTER
74
SHIFTING FORK ADDITIONAL GEAR CLUSTER
77
STUD SHIFTING FORK TO SHIFTING ROD TO 001 265 82 05
80
SLIDE SHIFTING FORK
83
SCREW SHIFTING FORK TO SHIFTING SHAFT TO 000 265 27 01,004245
86
NUT STRAP TO SUPPORT,5 149419
89
DETENT , Replaced By: A0002601773
89
DETENT SHIFTING ROD DETENT
92
DETENT SHIFTING ROD DETENT
95
PIN , Replaced By: A0009976010
95
PIN ADDITIONAL GEAR CLUSTER
98
SCREW PLUG
101
SEAL RING VALVE TO VALVE,K 025179
104
BALL SHIFTING CYLINDER
107
BOOT , Replaced By: A0002670697
107
BOOT SHIFTING SHAFT
110
PISTON ADDITIONAL GEAR CLUSTER
113
GUIDE SHIFTING SHAFT
113
GUIDE , Replaced By: A0002671059
116
SEAL RING , Replaced By: A0169973747
116
SEAL RING SHIFTING SHAFT
119
NUT CONSOLE TO SUPPORT
119
NUT , Replaced By: N910113016001
122
SHIFTING CYLINDER , Replaced By: A0002670419
122
SHIFTING CYLINDER HOUSING , Replaced By: A0002672119
122
SHIFTING CYLINDER HOUSING , Replaced By: A0002670419
122
SHIFTING CYLINDER ADDITIONAL GEAR CLUSTER
125
SCREW CLUTCH TO FLYWHEEL
128
SPRING WASHER STEERING COLUMN BRACKET TO CAB
131
SEAL RING SHIFTING CYLINDER
134
SEAL RING SHIFTING CYLINDER
134
SEAL RING , Replaced By: A0229970148
