Поз.
Артикул
Описание
20
CYLINDR. ROLLER BEARING MAIN SHAFT,FRONT
26
LOCK RING P.T.O.
29
MAIN SHAFT ,085136
32
LOCK RING AS REQUIRED 3.20 MM
32
LOCK RING DRIVE GEAR
32
LOCK RING AS REQUIRED 2.60 MM
32
LOCK RING AS REQUIRED 2.70 MM
32
LOCK RING AS REQUIRED 2.50 MM
32
LOCK RING AS REQUIRED 3.00 MM
32
LOCK RING AS REQUIRED 2.40 MM
32
LOCK RING AS REQUIRED 2.80 MM
32
LOCK RING AS REQUIRED 2.90 MM
32
LOCK RING AS REQUIRED 2.30 MM
32
LOCK RING AS REQUIRED 2.20 MM
32
LOCK RING AS REQUIRED 3.10 MM
35
SPACER WASHER MAINSHAFT, AS REQUIRED 3.30 MM
35
SPACER WASHER MAINSHAFT, AS REQUIRED 3.00 MM
35
SPACER WASHER MAINSHAFT, AS REQUIRED 4.30 MM
35
SPACER WASHER MAINSHAFT, AS REQUIRED 3.70 MM
35
SPACER WASHER MAINSHAFT, AS REQUIRED 3.50 MM
35
SPACER WASHER AS REQUIRED 5.20 MM
35
SPACER WASHER MAINSHAFT, AS REQUIRED 4.00 MM
35
SPACER WASHER AS REQUIRED 4.90 MM
35
SPACER WASHER AS REQUIRED 4.60 MM
38
FOLLOWER CONSTANT,055556 -718.540 , 055924 -718.250 , 056006 -718.254
38
FOLLOWER CONSTANT
41
SYNCHRONIZER RING 1ST THRU 4TH SPEED
41
SYNCHRONIZER RING , Replaced By: A0002626834
44
SYNCHRONIZER BODY CONSTANT
47
SPRING SPLITTER BOX
50
SPRING SPLITTER BOX
53
END PIECE SPLITTER BOX
56
SLIDING COLLAR 1ST THRU 4TH SPEED
59
FOLLOWER 5TH AND 6TH SPEED TO 000 262 45 15
59
FOLLOWER RING 3RD SPEED
62
BUSHING 5TH SPEED GEAR
65
NEEDLE BEARING ,10/20879179, 50/60880935
68
GEAR 5TH SPEED
68
GEAR , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 055555 -718.540 , 055923 -718.250 , 056005 -718.254, Replaced By: A0002624515, +001A0002623740
71
NEEDLE BEARING , Replaced By: A0139819110
71
NEEDLE BEARING 4TH SPEED GEAR
74
GEAR 4TH SPEED
77
SYNCHRONIZER BODY 3RD AND 4TH SPEED,10/20879180, 50/60880936
80
LOCK AS REQUIRED 2.30 MM,10/20879180, 50/60880936
80
LOCK AS REQUIRED 2.20 MM
80
LOCK RING , Replaced By: A3872626373
80
LOCK , Replaced By: A3872626173
83
FOLLOWER 1ST AND 2ND SPEED
86
NEEDLE BEARING , Replaced By: A0129815910
86
NEEDLE BEARING , Replaced By: A0129815910
86
NEEDLE BEARING , Replaced By: A0129815910
89
GEAR 3RD SPEED
92
NEEDLE BEARING , Replaced By: A0139819210
92
NEEDLE BEARING , Replaced By: A0139819210
95
GEAR 2ND SPEED
98
SYNCHRONIZER RING
98
SYNCHRONIZER RING 1ST AND 2ND SPEED TO 000 262 29 35
101
SYNCHRONIZER BODY 1ST AND 2ND SPEED
104
LOCK AS REQUIRED 2.90 MM
104
LOCK AS REQUIRED 2.80 MM
104
LOCK RING , Replaced By: A3872624373
107
FOLLOWER 1ST AND 2ND SPEED
110
SLIDING COLLAR 1ST AND 2ND SPEED
113
NEEDLE BEARING , Replaced By: A0029811710
113
NEEDLE BEARING
113
NEEDLE BEARING , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
113
NEEDLE BEARING
113
NEEDLE BEARING REVERSE SPEED GEAR
113
NEEDLE BEARING
116
GEAR 1ST SPEED, THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE
119
FOLLOWER RING REVERSE SPEED
122
BUSHING , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
122
BUSHING REVERSE SPEED
125
NEEDLE BEARING REVERSE SPEED GEAR
128
GEAR REVERSE SPEED
128
GEAR REVERSE SPEED
131
BALL BEARING , Replaced By: N000625536314
131
CYLINDR. ROLLER BEARING MAIN SHAFT,REAR, Replaced By: A0109818801
131
CYLINDR. ROLLER BEARING MAIN SHAFT,REAR
131
CYLINDRICAL BEARING MAIN SHAFT,REAR
131
CYLINDR. ROLLER BEARING
131
TAPERED ROLLER BEARING , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
131
CYLINDR. ROLLER BEARING
134
SNAP RING MAIN SHAFT,REAR
137
DRIVE GEAR SPEEDOMETER DRIVE, L.H. TURN,10/50 792024, 20/60 766368
137
DRIVE GEAR SPEEDOMETER DRIVE
140
SHAFT SPEEDOMETER DRIVE
143
DRIVE GEAR SPEEDOMETER DRIVE
143
DRIVE GEAR SPEEDOMETER DRIVE
146
FLANGE MAIN SHAFT OUTPUT
149
THRUST WASHER , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
149
THRUST WASHER. SEAL RING DRIVEN FLANGE TO DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
152
SCREW BEARING BRACKET TO SIDE MEMBER
152
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
155
LOCK
155
LOCK , Replaced By: A3859941032
