Поз.
Артикул
Описание
65
FLANGE SECOND BRAKE,010342
65
FLANGE ,000348, 720.430000051, 720.432, Replaced By: A3052721345, +002A3059940325, +004A3059940425, +012N000931008047
68
CYLINDER SECOND BRAKE
71
CYLINDER
74
PISTON
74
PISTON , Replaced By: A1262779632
77
SEAL RING
80
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0099971645
80
SEAL RING REVERSE BRAKE
83
COVER
86
SPRING1.40X12.50X83 MM
89
SPRING1.00X8.50X87 MM
92
SPRING RETAINER
95
LOCK RING
98
CLAMP CYLINDER TO HOUSING
101
BRACKET CYLINDER TO HOUSING
104
SCREW BRACKET TO TAIL LAMP BRACKET
107
LOCK SECOND BRAKE
107
LOCK SECOND BRAKE
110
SCREW SUPPORT TO FENDER
110
SCREW. CAP BOLT SEAT MOUNTING M8X35
110
SCREW , Replaced By: N000912008204
110
SCREW , Replaced By: N304017008018
113
SPRING WASHER , Replaced By: N000137008212
113
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
116
OIL GUIDE FIRST BRAKE
119
SEAL RING FIRST AND SECOND BRAKES
119
SEAL RING , Replaced By: A0139977848
122
NEEDLE BEARING ADDITIONAL GEAR CLUSTER
125
NEEDLE BEARING , Replaced By: A0069817510
125
NEEDLE BEARING40X55X20 MM
128
SUN GEAR , EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 016124, Replaced By: A3072720207
128
SUN GEAR
131
DISC SUPPORT SECOND BRAKE,THIRD CLUTCH,AND REVERSE CLUTCH
134
LOCK RING , Replaced By: A3872620673
134
LOCK DISC SUPPORT, AS REQUIRED 2.70 MM,016125
134
LOCK DISC SUPPORT, AS REQUIRED 2.60 MM,016125
134
LOCK
137
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.10 MM
137
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
140
ROLLER BEARING ADDITIONAL GEAR CLUSTER HOUSING TO TRANSMISSION CASE
143
GUARD PLATE , Replaced By: A3012720062
143
GUARD PLATE49.3X65 MM
149
PLANETARY CARRIER , Replaced By: A3052700743
149
PLANETARY CARRIER FRONT
152
BUSHING FRONT,014960
152
BUSHING FRONT,014961
155
GUARD PLATE PLANET GEAR
158
GUARD PLATE PLANETARY CARRIER
161
SCREW PLANETARY CARRIER
164
REPAIR KIT PLANETARY CARRIER
167
SPACER WASHER PLANETARY CARRIER, AS REQUIRED 0.10 MM
167
SPACER WASHER PLANETARY CARRIER, AS REQUIRED 0.50 MM
167
SPACER WASHER RETARDER COUPLING FLANGE, AS REQUIRED 0.30 MM
170
WASHER ADDITIONAL GEAR CLUSTER
173
NEEDLE BEARING TORSIONAL VIBRATION DAMPER
173
NEEDLE BEARING , Replaced By: A0159816710
176
GUARD PLATE PLANET GEAR
179
NEEDLE BEARING ANNULUS CARRIER
179
NEEDLE BEARING , Replaced By: A0049813610
182
LOCK DRIVE SHAFT
185
ANNULUS FRONT
188
ANNULUS CARRIER
191
LOCK ANNULUS TO ANNULUS SUPPORT
194
NEEDLE BEARING ADDITIONAL GEAR CLUSTER
197
NEEDLE BEARING30X35X17 MM
197
NEEDLE BEARING , Replaced By: A0069817410
197
NEEDLE BEARING , Replaced By: A0069817410
999
DISC , THE OLD PART MUST NO LONGER BE INSTALLED
999
DRIVE SHAFT ,004376-006909, Replaced By: A3072702625, +003A3072570659
999
DRIVE SHAFT , FROM TRANSMISSION 004075 ALSO INSTALLED ON 004049,004054-004056,004073004375, Replaced By: A3072702625, +001A3072570659, +001A3002720331, +001A3012720055
999
DRIVE SHAFT ,006910014716
999
INNER DISC , THE OLD PART MUST NO LONGER BE INSTALLED
