Поз.
Артикул
Описание
5
FLANGE P.T.O.
5
FLANGE , Replaced By: A3522700120
77
LEVER LEVER TO SHIFTING SHAFT
80
SPEEDOMETER DRIVE
83
OIL FILLER PIPE
86
OIL DIPSTICK
86
OIL DIPSTICK
86
OIL DIPSTICK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 750307, Replaced By: A3972700283
92
BRACKET POS. CABLE,XB209706
92
BRACKET LINE MOUNTING
98
CLAMP FEED LINE TO THERMOSTAT
107
SCREW AIR COMPRESSOR LINE
113
WASHER COMPRESSED AIR LINE TO BRACKET
113
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
116
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
119
NUT SPRING-LOADED PUSH ROD
179
FITTING EXHAUST BRAKE SWITCH TO SIGNAL PRESSURE CONNECTION AT TRANSMISSION
179
ELBOW FITTING LINE CONNECTION, UP TO CHASSIS 4 329112,FROM CHASSIS SEE SA 25 009
179
FITTING , Replaced By: A0009907171
182
UNION NUT
185
GLAND , Replaced By: A0019901667
188
FITTING EXHAUST BRAKE SWITCH TO SIGNAL PRESSURE CONNECTION AT TRANSMISSION
197
SWITCH P.T.O. TELL-TALE LAMP
200
SWITCH DECLUTCHING START UNIT
200
SWITCH , Replaced By: A0015457511
