Поз.
Артикул
Описание
126
LINE FROM FITTING TO CLUTCH BOOSTER
129
LINE
132
LINE
135
LINE FROM CLUTCH HOSE TO SLAVE CYLINDER
138
LINE CLUTCH MASTER CYLINDER A0002952718,100406
138
LINE CLUTCH MASTER CYLINDER A0002952718,100406
138
LINE CLUTCH MASTER CYLINDER A0002902112,100406
141
GLAND LINE CONNECTION
144
UNION NUT LINE CONNECTION
147
UNION SCREW
150
HOSE FROM HYDRAULIC HOSE TO CLUTCH SLAVE CYLINDER
153
HOSE MASTER CYLINDER,OIL TANK,HYDRAULIC LINES
156
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
159
UNION NUT
162
GLAND , Replaced By: A0019901667
165
SLEEVE LEAK LINE
168
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
171
CONNECTION FITTING ,880809
171
FITTING , Replaced By: A0039978972
174
BRACKET POS. CABLE,XB209706
177
BRACKET
180
CLAMP LINE MOUNTING
180
CLAMP ,K 147121, Replaced By: N000000000319
186
CLAMP COMPRESSED AIR LINE MOUNTING
189
SCREW FUEL LINE TO BRACKET
192
SCREW , Replaced By: N304017010040
193
SHEET METAL SCREW HYDRAULIC LINE
195
LOCK WASHER T-FITTING TO BRACKET
198
LOCK WASHER CABLE TO FUSE BOX
201
WASHER BODY REAR SUPPORT TO SIDE MEMBER
202
WASHER PLUG SOCKET TO BRACKET
204
NUT
205
NUT BRACKET TO SIDE MEMBER,XB209706
207
CLAMPING PIECE LINE MOUNTING
210
CLUTCH BOOSTER CLUTCH PEDAL PRESSURE BOOST
210
CYLINDER , Replaced By: A0002952718, +001A3842908214, +001A3822947140
213
BREATHER , Replaced By: A3933280065
216
BRACKET CYLINDER TO 000 290 21 12,100406
216
BRACKET CYLINDER TO 000 290 21 12,100406
216
BRACKET CYLINDER TO 0002902112,087894
219
NUT CYLINDER TO BRACKET TO0002902112
222
SCREW SWITCH TO BRACKET 8X16
225
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
228
FITTING , Replaced By: A0039979972
228
FITTING QUICK BREATHER VALVE,REAR, CONNECTION: "23"
231
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
231
SEAL RINGTO 000 553 03 05,000 553 18 05,
999
GASKET KIT CYLINDER TO 000 290 21 12
999
GASKET KIT CYLINDER TO 000 295 27 18
