Поз.
Артикул
Описание
5
AIR CLEANER
11
FILTER ELEMENT
14
NUT
20
FASTENER
23
SCREW , Replaced By: N304017008034
26
WASHER , Replaced By: N000125008443
29
NUT , Replaced By: N913004008001
62
AIR INTAKE PIPE REAR
65
AIR INTAKE PIPE CENTRAL
68
AIR INTAKE PIPE FRONT
71
BRACKET AIR INTAKE PIPE,REAR
74
BRACKET AIR INTAKE PIPE,REAR
77
CLAMP AIR INTAKE PIPE TO BRACKET
80
SCREW , Replaced By: N000933008134
83
SCREW CONNECTOR
86
NUT , Replaced By: N913004008001
89
NUT , Replaced By: N913004006001
92
HOSE INTAKE PIPE TO AIR CLEANER
92
HOSE INTAKE PIPE TO AIR CLEANER
95
LOOM TIE AIR INTAKE PIPE TO AIR CLEANER
98
CLAMP , Replaced By: N000000000678
101
AIR INTAKE PIPE FROM AIR CLEANER TO TURBOCHARGER
104
PIPE ELBOW FROM AIR CLEANER TO TURBOCHARGER
107
HOSE INTAKE PIPE TO AIR CLEANER
107
HOSE INTAKE PIPE TO AIR CLEANER
110
BOOT PIPE ELBOW TO TURBOCHARGER
113
CLAMP , Replaced By: N000000000678
116
MAINTENANCE INDICATOR AIR CLEANER
119
SCREW , Replaced By: N304017006020
122
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
125
NUT BALL PIVOT TO LEVER
128
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
131
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
134
UNION NUT
137
GLAND , Replaced By: A0019901667
140
SLEEVE LEAK LINE
143
FITTING , Replaced By: A0009907171
146
FITTING 3/2-WAY VALVE,CONNECTION: "30"
149
SEAL RING PNEUMATIC VALVE
149
SEAL RING , Replaced By: N007603010110
