Поз.
Артикул
Описание
5
HOUSING TRANSMISSION LOCK USED WITH P.T.O.
11
LEVER TRANSMISSION LOCK
16
BALL PIVOT BOTTOM B13X5 MM
21
SEAL RING SHIFTING SHAFT
26
THRUST PIECE SHIFTING SHAFT
31
EXPANSION PLUG
36
CLAMPING PIN GATE INDICATOR TO SHIFTING ROD,275875
36
CLAMPING PIN , Replaced By: N308750006004
42
PLUG SHIFTING SHAFT
47
SCREW SHIFTING SHAFT M 8X20
53
LOCK PLATE ANNULUS, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
61
PIN AS REQUIRED 46.0 MM
61
PIN AS REQUIRED 45.5 MM
61
PIN AS REQUIRED 45.6 MM
61
PIN , Replaced By: A3852610874
61
PIN , Replaced By: A3852610874
61
PIN , Replaced By: A3852610574
61
PIN , Replaced By: A3852610374
67
SCREW EXHAUST MUFFLER TO STRAP
70
VALVE GEAR INTERLOCK
70
VALVE , Replaced By: A0002606457
72
SWITCH 3/2-WAY VALVE WABCO
74
REPAIR KIT , Replaced By: A0002601268
74
REPAIR KIT 3/2-WAY VALVE WABCO
76
SCREW , Replaced By: N304017008042
76
SCREW SHOCK ABSORBER TO CONSOLE
78
LEVER TRANSMISSION LOCK
82
BALL PIVOT BOTTOM B13X5 MM
82
BALL PIVOT
91
WASHER BRACKET TO LEFT SIDE MEMBER
91
WASHER , Replaced By: N009021008213
96
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
102
SCREW CLAMP TO BRACKET AND TO PIPE
102
SCREW , Replaced By: N304017008021
102
SCREW PIPE CLAMP
107
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
107
PULL ROD TRANSMISSION LOCK
107
PULL ROD ,082680
118
BALL SOCKET ROD TO BALL PIVOT
126
NUT
132
SNAP RING
138
SECURING CLIP. CIRCLIP
