Поз.
Артикул
Описание
5
CASE. HOUSING
8
CASE
14
DRIVE SHAFT NUMBER OF TEETH: 25, UP TO TRANSMISSION 029242 FOR GEAR SET 43:25,RATIO1.07XENGINE REVOLUTION
20
CYLINDR. ROLLER BEARING FRONT
23
CYLINDR. ROLLER BEARING REAR DRIVE SHAFT,324180
26
SPACER WASHER AS REQUIRED 0,30 MM
29
SEAL RING OIL DISTRIBUTOR BLOCK
29
SEAL RING , Replaced By: A0129979847
29
SEAL RING , Replaced By: A0229974147
32
COVER REAR P.T.O.
38
SCREW BRACKET TO FRAME SIDE MEMBER
41
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
41
SPRING WASHER CAB FLOOR
44
COUPLING FLANGE
47
SEAL RING FLANGE TO TRANSMISSION CASE COVER
50
SHIM FLANGE TO TRANSMISSION CASE COVER
53
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
53
SPRING WASHER CAB FLOOR
56
SCREW BRACKET TO FRAME
59
INTERMEDIATE SHAFT (OUTPUT SHAFT)
62
SPRING DRIVE SHAFT
65
BALL P.T.O. SHAFT
68
SLIDING COLLAR
71
RING INTERMEDIATE SHAFT
74
RING INTERMEDIATE SHAFT
77
SLIDING COLLAR P.T.O.
80
GEAR NUMBER OF TEETH: 43, UP TO TRANSMISSION 029242
83
THRUST WASHER DRIVE GEAR
86
CYLINDR. ROLLER BEARING REAR DRIVE SHAFT
89
LOCK RING BEARING TO DRIVE SHAFT,183596
89
LOCK AS REQUIRED 2.30 MM
92
SPACER WASHER AS REQUIRED 4.20 MM, PIECES ARE INAPPLICABLE IT A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
92
SPACER WASHER AS REQUIRED 3.80 MM, PIECES ARE INAPPLICABLE IT A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
92
SPACER WASHER AS REQUIRED 3.60 MM, PIECES ARE INAPPLICABLE IT A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
95
COVER REAR P.T.O., PIECES ARE INAPPLICABLE IT A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
95
COVER , Replaced By: A0002644611, +001A0002649580
95
COVER , Replaced By: A0002644411, +001A0002647480
101
SCREW BRACKET TO FRAME SIDE MEMBER
104
SPRING WASHER CAB FLOOR
104
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
107
COUPLING FLANGE P.T.O.
113
SEAL RING INSIDE
113
SEAL RING , Replaced By: A0129970647
113
SEAL RING , Replaced By: A0089973347
116
THRUST WASHER. SEAL RING DRIVEN FLANGE TO DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
119
LOCK SCREW
119
LOCK , Replaced By: A3859941032
122
SCREW , Replaced By: N000931012186
122
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD 12X70
125
SCREW , Replaced By: A3959900501
125
SCREWM 16X16X20X45
128
SHIFTING FORK
131
SEAL RING
134
THRUST WASHER
137
SHIFT LEVER P.T.O. CONTROL
140
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
140
SPRING WASHER , Replaced By: N000137008212
143
SCREW , Replaced By: N304017008034
143
SCREW BRACKET TO CROSS CONNECTION STRUT
146
STUD BOLT
149
SPACER WASHER AS REQUIRED 1.60 MM
149
SPACER WASHER AS REQUIRED 1.50 MM
149
SPACER WASHER P.T.O. HOUSING
149
SPACER WASHER AS REQUIRED 1.90 MM
149
SPACER WASHER AS REQUIRED 1.30 MM
149
SPACER WASHER AS REQUIRED 1.80 MM
149
SPACER WASHER AS REQUIRED 1.00 MM
149
SPACER WASHER AS REQUIRED 1.10 MM
149
SPACER WASHER AS REQUIRED 1.70 MM
152
WASHER HOUSING,FRONT
155
GASKET P.T.O.
155
GASKET , Replaced By: A0012640280
158
NUT BRACKET TO SUPPORT AND TO END PIECE
158
NUT BATTERY CABLE
161
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
164
SCREW SUPPORT TO CROSS MEMBER M 10X28
170
COVER
173
GASKET COVER TO P.T.O. CASE
176
SCREW BRACKET TO SIDE MEMBER
179
SPRING WASHER STEERING COLUMN BRACKET TO CAB
188
SHIFTING CYLINDER P.T.O. CONTROL
188
SHIFTING CYLINDER , Replaced By: A0002606263
191
SEAL RING
194
SPRING
197
SPRING
200
STOP RING
203
SNAP RING
206
BOOT
206
BOOT , Replaced By: A0002640696
209
NUT , Replaced By: N304035010001
209
NUT
212
YOKE , Replaced By: A0009962801
212
YOKE
215
PINM 8 X 16
215
PIN , Replaced By: N918001008002
218
BRACKET SHIFTING CYLINDER
218
BRACKET PNEUMATIC SHIFTING CYLINDER
221
SCREW BRACKET TO SIDE MEMBER M10X38
224
SPRING WASHER STEERING COLUMN BRACKET TO CAB
227
STRAINER
230
WASHER
233
PIN PULL ROD TO SHIFT LEVER
236
WASHER SHIFTING CYLINDER
239
COTTER PIN LEVER TO ROD
239
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
242
SENDER UNIT , Replaced By: A0105421217, +002A0045453926
242
SENDER UNIT , Replaced By: A0025452014
242
SWITCH
242
SWITCH
248
REPAIR KIT PNEUMATIC SHIFTING CYLINDER TO 000 260 66 63
251
SCREW PLUG
254
SEAL RING SOLENOID VALVE A 18X24
260
PLUG , Replaced By: A0009973435
260
PLUG , Replaced By: A0009977535
260
PLUG , Replaced By: A3529970032
260
COVER , Replaced By: A0009977535
260
SCREW PLUG BELL HOUSING
263
EXPANSION PLUG SPEEDOMETER DRIVE
275
SCREW PLUG OIL DRAIN, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
999
P.T.O.N90/10,1,53 X N
999
P.T.O.N90/10,1,53 X N
