Поз.
Артикул
Описание
5
SHAFT (SHIFTING SHAFT)
8
FOLLOWER SHIFTING SHAFT
11
CYLINDRICAL ROLLER SHIFTING SHAFT
14
ROLLER SHIFTING SHAFT
17
FOLLOWER REVERSE SPEED
20
PIN SHIFTING SHAFT
23
FOLLOWER REVERSE SPEED
26
FOLLOWER 1ST AND 2ND SPEED
29
FOLLOWER 3RD AND 4TH SPEED
32
FOLLOWER SHIFTING SHAFT
35
SCREW FOLLOWER TO SHIFTING SHAFT
38
FOLLOWER SHIFTING SHAFT
41
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
44
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
47
SHIFTING SEGMENT SHIFTING SHAFT
50
SPACER WASHER SHIFTING SHAFT
50
SPACER WASHER , Replaced By: A0002680052
53
BUSHING SHIFTING SHAFT,BOTTOM
56
SPACER WASHER SHIFTING SHAFT
59
SPRING SHIFTING SHAFT,BOTTOM
62
SPACER RING SHIFTING SHAFT,BOTTOM
65
CLAMPING SLEEVE SHIFTING SHAFT,BOTTOM
68
COVER SHIFT LEVER TO TRANSMISSION
71
SHIFT LEVER
71
SHIFT LEVER , Replaced By: A0002684130
74
SCREW SHIFTING ROD TO JOINT
77
SPRING WASHER STEERING COLUMN BRACKET TO CAB
80
NUT , Replaced By: N304032010002
80
NUT
83
JOINT FROM SHIFTING ROD TO CONNECTOR
86
HEXAGON NUT
86
NUT , Replaced By: A0002680472
86
NUT , Replaced By: N913004010010
86
NUT , Replaced By: N910113010002
89
NUT , Replaced By: N308673014001
89
NUT BRACKET TO SIDE MEMBER,K 035196
92
CONNECTOR SHIFTING TUBE TO SHIFT LEVER
95
JOINT , Replaced By: A0002686189
95
JOINT TOP
95
BALL JOINT UPPER PULL ROD
98
NUT BRACKET TO TELESCOPIC TUBE,K 142858
101
NUT PULL ROD
104
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLY
107
JOINT , Replaced By: A0002686289
107
JOINT BOTTOM
110
NUT STRAP TO SUPPORT,5 149419
113
BRACKET BRACING
113
BRACKET LOWER SHIFTING ROD,001876,5 K 90 GP003321,5 S 90 GP
116
SCREW CLUTCH TO FLYWHEEL
119
SPRING WASHER STEERING COLUMN BRACKET TO CAB
122
COVER , Replaced By: A0002686105, +002A0009977535
122
COVER SHIFT CASE
125
GASKET SHIFT CASE
125
GASKET , Replaced By: A0002685780
128
EXPANSION PLUG ROD END
131
EXPANSION PLUG HOUSING,BOTTOM
134
SCREW PLUG
137
SCREW , Replaced By: N304014010004
137
SCREW BRACKET TO BELL HOUSING
137
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
137
SCREW CLUTCH TO FLYWHEEL
137
SCREW SHIFT CASE TO TRANSMISSION M 10X105
140
SPRING WASHER STEERING COLUMN BRACKET TO CAB
143
PIN INTERLOCK PIN
146
BUSHING SHIFT CASE,TOP
149
BEARING COVER SHIFTING DOME
149
BEARING COVER , Replaced By: A0002680634, +001N000906010000
149
BEARING COVER , Replaced By: A0002680034
152
SCREW PLUG STABILIZER
155
GASKET SHIFT CASE,TOP AND BOTTOM
155
GASKET , Replaced By: A0002685180
158
SCREW , Replaced By: N000933008337
158
SCREW , Replaced By: A0099900101
158
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
161
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
161
SPRING WASHER , Replaced By: N000137008212
164
VALVE BREATHER
167
BUSHING SHIFTING DOME,TOP
170
SEAL RING SHIFTING SHAFT
173
BOOT SHIFTING SHAFT
176
PIN SHIFT CASE,BOTTOM
179
SPRING SHIFT CASE
182
NEEDLE BEARING REAR DRIVE SHAFT
185
COVER SHIFT CASE,BOTTOM
188
SCREW FRONT AXLE REGULATING SOLENOID VALVE
188
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
188
SCREW , Replaced By: N000933008134
188
SCREW , Replaced By: N304017008027
191
STUD COVER TO SHIFT CASE
194
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
194
SPRING WASHER , Replaced By: N000137008212
197
NUT , Replaced By: N304032008006
197
NUT
200
CABLE PULLEY SHIFT CASE,BOTTOM
203
PIN SHIFT CASE,BOTTOM
206
SPRING SHIFT CASE,FRONT
209
SCREW PLUG SHIFT CASE,BOTTOM
212
SEAL RINGTO 376 131 74 01
215
PIN
218
SLOTTED GATE
221
GASKET VALVE TO TRANSMISSION
221
GASKET , Replaced By: A0002685080
224
SCREW PLUG TOP AND BOTTOM
227
SCREW CLAMP TO BRACKET AND TO PIPE
230
COVER SHIFT CASE
233
GASKET , Replaced By: A0002685880
233
GASKET SHIFT CASE
236
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
236
SCREW , Replaced By: N304017008016
239
SPRING WASHER , Replaced By: N000137008212
239
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
242
DETENT SHIFT CASE
242
DETENT , Replaced By: A0002602173
245
LOCK PLATE SHIFT CASE
248
COVER LATERAL
251
GASKET LATERAL
251
GASKET , Replaced By: A0002685580
254
SCREW BRACKET TO TAIL LAMP BRACKET
