Поз.
Артикул
Описание
5
VALVE 3/2-WAY VALVE,FOUR-CIRCUIT PROTECTIVE VALVE,SOLENOID VALVE,131097,5 S 110 GPA131453,5 K 110 GPA
5
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0012602757
5
VALVE , Replaced By: A0012602757
8
GASKET , Replaced By: A0002685880
8
GASKET SHIFT CASE
14
SCREW , Replaced By: N304017008021
14
SCREW PIPE CLAMP
17
SPRING WASHER , Replaced By: N000137008212
23
SCREW PLUGM 12X1.5
26
SEAL RING LINE CONNECTION
29
SHIFTING CYLINDER ADDITIONAL GEAR CLUSTER WESTINGHOUSE
32
COVER SHIFTING CYLINDER
32
COVER
35
BUSHING SHIFTING CYLINDER
35
BUSHING , Replaced By: A0002684950
38
YOKE SHIFTING CYLINDER
41
NUT , Replaced By: N308675014000
41
NUT , Replaced By: N308675014002
44
BOOT SHIFTING CYLINDER
44
BOOT , Replaced By: A0002640596
44
BOOT , Replaced By: A0002640796
47
STRAINER SHIFTING CYLINDER
50
GASKET KIT SHIFTING CYLINDER
53
REPAIR KIT SHIFTING CYLINDER TO 000 260 39 63,003529,5 S 90 GPA001872,5 K 90 GPA
56
BRACKET SHIFTING CYLINDER,LEFT
56
BRACKET , Replaced By: A0002650436, +001N000094004046, +001N000125015013, +003N000933010105
59
SCREW REAR EXHAUST PIPE TO MUFFLER
65
DOWEL PIN SHIFTING CYLINDER TO BRACKET TO 000 267 01 40,04 40,
68
EXPANSION PLUG TRANSMISSION CASE,SIDE
71
SCREW PLUG
74
PIN POWER CYLINDER TO EXHAUST SHUNT FLAP
77
WASHER
80
COTTER PIN STRAP TO SUPPORT
86
HOSE FROM 3/2-WAY VALVE TO SHIFTING CYLINDER, ORDER BY THE METER
89
BANJO UNION
92
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
95
SEAL RING
