Поз.
Артикул
Описание
10
SEAL REFRIGERANT LINE
10
SEAL LEFT REAR WHEEL ARCH, A 04134320060828807
20
PLUG TO BODY 10 MM, J 78221020091022
20
PLUG ENGINE HOOD 10 MM, J 25077320051107
20
STOP PLUG 3RD STOP LAMP
20
STOP PLUG TOP CENTER 11 MM
30
PLUG SIDE MEMBER,INSIDE LEFT 15 MM
30
PLUG CROSS MEMBER IN THE REAR, LEFT 15 MM
40
PLUG20 MM
40
STOP PLUG CROSS MEMBER 20 MM
45
WATER DRAIN GROMMET FRONT LEFT BOTTOM
45
BUTTONABLE GROMMET ROCKER PANEL AT CENTER LEFT
50
EXPANSION PLUG VENTILATION BORE IN WHEELHOUSE, ONLY FOR REPAIR PURPOSES
50
EXPANSION PLUG
50
PLUG CROSS MEMBER IN THE REAR, RIGHT 25 MM
70
EXPANSION PLUG IN FLOOR BELOW REAR SEAT BENCH
70
STOP PLUG E-RECESS CENTER 30 MM
80
STOP PLUG BRAKE CABLE
100
BOLT. SCREW
350
GROMMET REAR BUMPER
370
STOP PLUG ROCKER PANEL LEFT REAR 20 MM
370
STOPPER WASHER INSIDE PART RIGHT 15X25 MM
370
EXPANSION PLUG WATER TANK 54 X 29, Replaced By: A0009976520
370
GROMMET RIGHT WHEELHOUSE
370
STOPPER WASHER25X35 MM
370
PLUG REAR SIDE MEMBER
370
SEAL LEFT REAR WHEEL ARCH
370
EXPANSION PLUG CROSSMEMBER BELOW WIND DEFLECTOR, LEFT 55X30 MM
380
STOP PLUG WHEELHOUSE INSIDE, LEFT REAR
380
STOP PLUG LONGITUDINAL MEMBER, TOP, RIGHT 10X20 MM
390
SEAL LEFT FRONT WHEEL ARCH
390
STOPPER WASHER AT CROSS MEMBER, REAR AXLE 20X30 MM
420
EXPANSION PLUG WHEELHOUSES, REAR FENDERS
430
GROMMET
440
TAKE-UP DEVICE JACK TAKE-UP DEVICE
450
ADHESIVE TAPE PIPING
