Поз.
Артикул
Описание
5
RAIL RIGHT, TO BE ADAPTED DURING ASSEMBLY
5
RAIL LEFT,P 718450
8
BOLT RUN TO BODY 10X1X28
8
HEXALOBULAR BOLT. SCREW
8
SCREW DOOR SLIDE MECHANISM TO DOOR
11
NUT MOUNTING FRAME TO SUPPORT M6
11
NUT , Replaced By: N913023006001
14
CATCH RIGHT
14
ADJUSTER. CATCH LEFT
17
SCREW BRACKET TO BRACKET
20
NUT
23
CAP LEFT
23
CAP RIGHT
26
HEXALOBULAR BOLT. SCREW
30
NUT HORN TO BRACKET M8
30
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
38
DOOR SLIDE MECHANISM RIGHT
38
DOOR SLIDE MECHANISM RIGHT
38
DOOR SLIDE MECHANISM LEFT
41
WASHER STRUT TO CROSS MEMBER
44
SEAL DOOR SLIDE MECHANISM TO DOOR
50
BOLT RUN TO BODY 10X1X28
50
HEXALOBULAR BOLT. SCREW
50
SCREW DOOR SLIDE MECHANISM TO DOOR
53
DOOR SLIDE MECHANISM LEFT TOP
53
DOOR SLIDE MECHANISM RIGHT TOP
56
HEXALOBULAR BOLT MOUNTING PARTS M8X16
59
BRACKET LEFT BOTTOM
59
BRACKET RIGHT BOTTOM
61
SCREW BRACKET TO BRACKET
62
HEXALOBULAR BOLT MOUNTING PARTS M8X16
65
DETENT , ONLY FOR AUSTRALIA CODE 625
65
DETENT TOP AND BOTTOM,LEFT AND RIGHT
68
SLIDE , ONLY FOR AUSTRALIA CODE 625
68
SLIDE
69
BUFFER
71
STOP , Replaced By: A6907600029
71
TRAVEL LIMITER
71
STOP BUFFER LEFT
74
SCREW BRACKET MOUNTING
74
HEXALOBULAR BOLT BACKREST TO REAR WALL M6X20
77
HEXALOBULAR BOLT WINDOW REGULATOR AT BRACKET AND DOOR M6X16
80
RUBBER BUFFER AT C-PILLAR,BOTTOM
83
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1119871540
86
EXPANSION PLUG
