Mercedes N304017006020 - Винт M 6 X 20 8.8

308 CDI, 311 CDI, 313 CDI, 316 CDI 903.621 TO IDENT-NR. R337626

46 STEERING - 180 HYDRAULIC LINES IL. 2

Поз.
Артикул
Описание
5
A9015003500
RADIATOR
5
A9015003600
RADIATOR
10
A0005016215
RADIATOR CAP
15
A0219977682
HOSE
20
A0005000185
SCREW WATER DRAIN
25
A1295450224
SWITCH,AUTOMATIC EXPANSION TANK, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
30
A0125450428
PIN BUSHING HOUSING BIPOLAR
35
A0015454426
ROUND PIN BUSHING4 MM2
50
A9015051288
COVERING RIGHT
55
A9015051088
COVERING LEFT
60
N304017006020
SCREW LICENSE PLATE TO BRACKET
65
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
65
N000125006421
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
70
A0009908991
NUT RETAINER
75
A9015051488
COVERING
80
N000000000453
SHEET METAL SCREW MODULE TO HOUSING
80
N007981004244
SHEET METAL SCREW , Replaced By: N000000000453
85
A0009943045
LOCK
90
A9015050488
COVERING TOP
90
A9015050988
COVERING
95
A6385040212
RUBBER MOUNTING RADIATOR BOTTOM
95
A6385040012
RUBBER MOUNTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6385040212
100
A9015040112
RUBBER MOUNTING RADIATOR MOUNTING,TOP
105
A9015040046
CLAMP RADIATOR MOUNTING,TOP
