Главная
›
Mercedes
›
VAN
›
414,408CDI,411CDI,413CDI,416CDI
›
904.662 FROM IDENT-NR. R337627, 5337627, A901274
›
83 HEATING/VENTILATION
›
130 HEAT EXCHANGER IL. 2
Mercedes A9018323923 - Шланг
414,408CDI,411CDI,413CDI,416CDI 904.662 FROM IDENT-NR. R337627, 5337627, A901274
83 HEATING/VENTILATION - 130 HEAT EXCHANGER IL. 2
Поз.
Артикул
Описание
59
A9018321315
PIPE LINE RETURN FROM HEAT EXCHANGER
59
A9018321415
PIPELINE HEATER BOOSTER TO RETURN PIPE
62
A9018321715
PIPE LINE FROM PIPE LINE TO HEAT EXCHANGER, FEED,09.2001
62
A9018321515
PIPELINE FROM STATIONARY HEATER TO HEATER BOOSTER
62
A9018320715
PIPE LINE FROM PIPE LINE TO HEAT EXCHANGER, FEED
65
A9018323823
HOSE
68
A9018323923
HOSE
68
A9018327823
HOSE
70
A9018321615
PIPELINE FROM HEATER BOOSTER TO ADDITIONAL HEAT EXCHANGER
71
A9018327423
HOSE WATER OUTLET
71
A9018327323
HOSE WATER INLET
73
A9018327523
HOSE WATER OUTLET
77
A9018323723
HOSE
80
N000000000667
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
81
A9018320814
BRACKET PIPE LINE TO BODY
82
A9019880281
FASTENER BUTTON. PUSH BUTTON
83
A0019951665
CLAMP PIPE LINE TO BODY
84
A0019951844
CLAMP2X 16-19 MM
85
A0049903051
SCREW COLLAR PIPE LINE TO FLOOR
86
A0004291040
BRACKET PIPE LINE TO BODY
89
A0019881581
FASTENER BUTTON ELECTRIC CABLE TO FIRE WALL
92
A0029972490
CABLE TIE310X5MM
92
A0019978390
LOOM TIE LINE MOUNTING 280 MM
95
A6509970090
LOOM TIE HOSE TO HEATING PIPE
