Поз.
Артикул
Описание
11
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
16
FITTING (PARTS KIT),LINE RUPTURE
21
UNION NUT LINE CONNECTION
26
GLAND LINE CONNECTION
31
SLEEVE LINE CONNECTION
36
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
41
PLASTIC PIPE RISING PIPE 4X6 MM
41
PLASTIC PIPE RISING PIPE 4X6 MM
41
PLASTIC PIPE RISING PIPE 4X6 MM
41
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
46
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
51
UNION NUT
56
SEAL CONE
56
GLAND , Replaced By: A0019901667
61
SLEEVE LEAK LINE
66
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
71
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
71
T-FITTING EXHAUST BRAKE LINE CONNECTION
76
LOOM TIE LINE MOUNTING
76
LOOM TIE BRAKE LINE MOUNTING
76
LOOM TIE LINE MOUNTING 280 MM
81
HOSE LEAK LINE, ORDER BY THE METER
86
BRACKET (T-FITTING) EXHAUST BRAKE LINE CONNECTION
86
BRACKET AT FITTING
86
BRACKET , Replaced By: A6204203686
96
T-FITTING EXHAUST BRAKE LINE CONNECTION
101
LOOM TIE BRAKE LINE MOUNTING
106
SCREW , Replaced By: N000000001146
106
SCREW CLAMP MOUNTING M 6X16
106
SCREW , Replaced By: A4609900601
106
SCREW EXHAUST PIPE TO BRACKET
111
NUT , Replaced By: N913004006001
111
NUT PUMP TO BRACKET
116
WASHER BRACKET TO CROSS MEMBER
121
VALVE , Replaced By: A0049975736
121
VALVE (3/2-WAY SOLENOID VALVE) KNORR
121
VALVE (3/2-WAY SOLENOID VALVE) EKS
121
VALVE (3/2-WAY SOLENOID VALVE) WABCO
124
GASKET KITKNORR
126
SEAL RINGWABCO
131
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
131
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
136
SEAL RINGTO 000 434 23 01
141
SEAL RINGTO 000 434 23 01
146
HANDLETO 000 434 23 01
151
CUP 3/2-WAY VALVE WABCO
156
SEAL RINGTO 000 434 21 01
161
SPRINGTO 000 434 21 01
166
STRAINERTO 000 434 21 01
171
REPAIR KIT 3/2-WAY VALVE BOSCH
171
REPAIR KIT 3/2-WAY VALVE WABCO
176
BRACKET SOLENOID VALVE
181
REINFORCEMENT DISTRIBUTOR TO CAB
186
SPRING WASHER AT CAB FLOOR
191
NUT SUCTION LINE TO OIL PUMP
196
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
201
NUT , Replaced By: N913004008001
201
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
206
HOLLOW SCREW HEATING CONNECTION
211
SEAL RING LINE CONNECTION
216
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
221
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
221
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
226
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
231
SEAL RING LINE CONNECTION
236
FITTING LINE CONNECTION, Replaced By: N000000006446
236
FITTING LINE CONNECTION
241
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30", NOT CARRIED AS A SPARE PART
246
DISTRIBUTOR EXHAUST BRAKE VALVE LINE CONNECTION
251
SCREW APPARATUS PLATE M 6X45
251
SCREW , Replaced By: N304017006027
256
WASHER COMPRESSED AIR LINE TO BRACKET
256
WASHER , Replaced By: N009021006208
261
NUT PUMP TO BRACKET
261
NUT , Replaced By: N913004006001
266
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
266
SCREW PLUG , Replaced By: N000908012009
271
HOLLOW SCREW HEATING CONNECTION
271
HOLLOW SCREW LINE CONNECTION
281
SEAL RING LINE CONNECTION
286
BRACKET LEFT, TO BE ADAPTED DURING ASSEMBLY
291
BRACKET AT CAB BEARING BRACKET
296
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
301
NUT BRACKET TO SIDE MEMBER
301
NUT , Replaced By: N910113014001
