Поз.
Артикул
Описание
18
TANK AT CAB REAR PANEL, 415 5 014668 416 5 000515 417 4 972023
21
RADIATOR CAP
24
RADIATOR CAP FILLER NECK
24
RADIATOR CAP FILLER NECK
27
BRACKET EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
30
SCREW BRACKET TO SIDE MEMBER
32
WASHER BRACKET TO RIGHT FENDER, 415 5 014668 416 5 000515 417 4 972023
34
NUT STRAP TO BRACKET
34
NUT , Replaced By: N910113010000
40
BRACKET (STRAP), 415 5 014668 416 5 000515 417 4 972023
43
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
46
SHIM , Replaced By: A3815010495
46
SHIM STRAP, 415 5 014668 416 5 000515 417 4 972023
49
SCREW END PIECE TO EXHAUST PIPE M 10X25
51
NUT , Replaced By: N910113010000
51
NUT STRAP TO BRACKET
53
WASHER RADIATOR TO RUBBER MOUNTING
53
WASHER , Replaced By: N000125010532
114
CONNECTOR , Replaced By: A3875010423
114
CONNECTOR AT WATER PUMP
116
GASKET CONNECTOR, Replaced By: A0002011080
116
GASKET , Replaced By: A4422010480
116
GASKET CONNECTOR, Replaced By: A0002011280
116
GASKET CONNECTOR, Replaced By: A0002011180
116
GASKET CONNECTOR
119
SCREW END PIECE TO EXHAUST PIPE M 10X25
121
SPRING WASHER STEERING COLUMN BRACKET TO CAB
124
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
126
COOLING WATER PIPE FROM WATER PUMP TO EXPANSION TANK
130
HOSE FROM WATER PUMP TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
133
CLAMP
133
CLAMP , Replaced By: N000000000670
136
BRACKET , Replaced By: A3834929141
136
BRACKET COOLING WATER LINE TO FRAME
139
CLAMP COOLING WATER LINE TO BRACKET,5 022370
142
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
142
SCREW , Replaced By: N304017008016
145
NUT , Replaced By: N913004008001
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
148
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
151
CLAMP COOLING WATER LINE TO BRACKET,5 022370
154
SCREW PIPE CLAMP
154
SCREW , Replaced By: N304017008021
156
NUT , Replaced By: N913004008001
156
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
156
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
FLANGE HEATING AND BREATHING, 415 5 014668 416 5 000515 417 4 972023
162
GASKET. SEAL DE-AERATION PIPE TO ENGINE
165
SCREW END PIECE TO EXHAUST PIPE M 10X25
167
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
169
BRACKET ENGINE CABLE HARNESS PLUG-CONNECTION,5 452356
169
BRACKET HEATING PIPE,5 301948
171
CLAMP FEED LINE TO THERMOSTAT
173
SCREW COVER PLATE TO BRACKET
175
NUT , Replaced By: N910113006001
175
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
177
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR, 415 5 014668 416 5 000515 417 4 972023
180
CLAMP , Replaced By: N000000000667
180
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
183
LINE HEATING,MOUNTED TOGETHER WITH RADIATOR AT RUBBER BUFFER, 415 5 014668 416 5 000515 417 4 972023
189
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
192
CLAMP , Replaced By: N000000000667
192
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
195
HOSE , Replaced By: A3635060135
195
HOSE , Replaced By: A3635060235
195
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
197
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
197
CLAMP25-40X13 MM
200
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
200
CLAMP , Replaced By: N000000000667
203
HOSE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
206
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
206
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
210
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
214
CLAMP , Replaced By: N000000000667
214
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
218
BREATHER PIPE FROM ENGINE TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
227
BRACKET FUEL LINE TO BELL HOUSING
227
BRACKET , Replaced By: A6454310740
230
BRACKET , Replaced By: A3524290740
230
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
236
SCREW EXHAUST PIPE TO BRACKET
239
WASHER , Replaced By: N000125010532
239
WASHER RADIATOR TO RUBBER MOUNTING
241
NUT STRAP TO BRACKET
241
NUT , Replaced By: N910113010000
248
CLAMP , Replaced By: N916016011202
248
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
248
CLAMP AT BRACKET
251
SCREW , Replaced By: N304017008016
251
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
254
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
254
NUT , Replaced By: N913004008001
254
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
257
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
260
CLAMP DELIVERY AND SUCTION LINES TO STEERING
260
CLAMP , Replaced By: A6739950001
263
SCREW COVER PLATE TO BRACKET
266
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
266
NUT , Replaced By: N910113006001
999
GASKET HEATING PIPE TO ENGINE
999
CLAMP , Replaced By: N000000000667
999
CLAMP , Replaced By: N916017011001
999
CLAMP ,K 147121, Replaced By: N000000000319
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N910113006001
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW , Replaced By: N000000001146
999
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
999
SCREW PLUG WATER DRAIN
999
SEAL RING FUEL LINE TO FEED PUMP
999
SCREW , Replaced By: N304017010028
999
SCREW , Replaced By: A4609900601
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017006018
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
SCREW STRAP TO BRACKET
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER , Replaced By: N000137008212
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW CLAMP MOUNTING M 6X16
999
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
PIPE ELBOW AT WATER PUMP,5 510518
999
PIPE ELBOW AT WATER PUMP,5 1935955 510517
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
999
BRACKET HEATING PIPE
999
RUBBER MOUNTING RADIATOR
999
HOSE , Replaced By: A6205012882
999
HOSE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
999
BREATHER PIPE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
PIPE ELBOW , Replaced By: A6555010756
999
PIPE ELBOW , Replaced By: A6205010556
999
CONNECTOR AT WATER PUMP
999
STRAP EXPANSION TANK TO BRACKET
999
STRAP EXPANSION TANK TO BRACKET
999
SHIM EXPANSION TANK TO BRACKET
999
SHIM EXPANSION TANK TO BRACKET
999
PIPE ELBOW , Replaced By: A6205010056
999
CONNECTOR , Replaced By: A6205010423
999
PIPE ELBOW AT WATER PUMP,5 193594
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
LINE (HEATING LINE),FROM ENGINE TO HEATER
999
TANK CAB,FRONT,5 129373
999
TANK (EXPANSION TANK)
999
BRACKET EXPANSION TANK
999
BRACKET EXPANSION TANK
999
BRACKET DE-AERATION LINE TO CAB
999
STRAP EXPANSION TANK,RIGHT
999
BREATHER PIPE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
STRAP EXPANSION TANK,LEFT
999
SHIM EXPANSION TANK,RIGHT
999
SHIM EXPANSION TANK,LEFT
999
BRACKET EXPANSION TANK,RIGHT
999
TANK ,5 129372, Replaced By: A6205000349, +001A6205012882, +001N916017020000
999
BRACKET EXPANSION TANK,LEFT
999
SCREW EXHAUST PIPE TO BRACKET
999
BRACKET OIL DIPSTICK TO RADIATOR
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
CLAMP , Replaced By: A3604300143
999
CLAMP , Replaced By: N916016008200
999
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
999
HOSE OVERFLOW, EXPANSION TANK
999
SCREW PLUG , Replaced By: N007604014101
999
CLIP CABLE HARNESS TO ROOF RAIL
999
CLAMP , Replaced By: N916017011000
999
RADIATOR CAP CENTRAL
999
RADIATOR CAP CENTRAL
999
GASKET O.D., 37 MM
999
GASKET O.D., 52 MM
999
TANK ON RADIATOR
