Поз.
Артикул
Описание
154
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
469
ADAPTER FITTING PASSAGE OF LINE THRU SIDE MEMBER,5 395033
469
ADAPTER FITTING , Replaced By: A0004296934
476
NUT BRACKET TO SIDE MEMBER
483
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
483
LINE , Replaced By: A6254293501
490
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
497
GLAND , Replaced By: A0019901967
497
SEAL CONE LINE CONNECTION
504
UNION NUT LINE CONNECTION
504
UNION NUT LINE CONNECTION, Replaced By: N000000006239
511
FITTING DIAPHRAGM CYLINDER,CONNECTION:
518
CLAMP HOSE TO FITTING AND TO OIL TANK
525
CLAMP 3/2-WAY SOLENOID VALVE
532
SCREW CLAMP TO BRACKET
532
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
539
WASHER , Replaced By: N009021006208
539
WASHER COMPRESSED AIR LINE TO BRACKET
546
NUT , Replaced By: N913004006001
546
NUT PUMP TO BRACKET
553
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
560
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
567
FITTING DELIVERY LINE TO PUMP
581
VALVE REAR AXLES I AND II BOSCH
581
VALVE FRONT AXLES I AND II "WABCO"
584
VALVE SEATWABCO
588
SEAL RING42.52X2.62 MM,WABCO
588
SEAL RING , Replaced By: A0179979048
595
SEAL RING74.20X5.70 MM,WABCO
602
SEAL RING82.22X2.62 MM,WABCO
605
REPAIR KIT RELAY VALVE WABCO
609
BRACKET RELAY VALVE TO CROSS MEMBER
616
SCREW BRACKET TO CROSS CONNECTION STRUT
616
SCREW , Replaced By: N304017008034
623
NUT , Replaced By: N913004008001
623
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
630
O-RING CHECK VALVE TO AIR RESERVOIR
637
THRUST RING CHECK VALVE TO AIR RESERVOIR
637
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
644
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
651
MUFFLER BRAKE PRESSURE REGULATOR BREATHING,5 419692
651
MUFFLER , Replaced By: A0004302370
651
MUFFLER TRAILER CONTROL VALVE
658
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
665
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
721
VALVE (REDUCTION VALVE) 1,15:1
721
VALVE (REDUCTION VALVE)
721
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0034291444
728
REPAIR KIT
728
REPAIR KIT REDUCTION VALVE
735
BRACKET REDUCTION VALVE, SIMPLE PART-PLEASE HAVE SHOP MADE
735
BRACKET UPPER EXHAUST PIPE TO BRACKET,4 726045
735
BRACKET , Replaced By: A3834929041
742
SCREW , Replaced By: N304017008034
742
SCREW BRACKET TO CROSS CONNECTION STRUT
749
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
749
SCREW , Replaced By: N304017008027
756
WASHER , Replaced By: N000125008443
756
WASHER EXHAUST MUFFLER TO STRAP
763
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
763
NUT , Replaced By: N913004008001
770
O-RING CHECK VALVE TO AIR RESERVOIR
777
THRUST RING CHECK VALVE TO AIR RESERVOIR
777
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
784
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
791
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
798
TEST CONNECTION
999
PRESSURE REGULATOR , Replaced By: A0024314306
999
LINE , Replaced By: A6254293501
