Поз.
Артикул
Описание
8
CLAMPING PIECE BATTERY POS. CABLE TO BRACKET
16
SCREW DISTRIBUTOR TO CAB
16
SCREW , Replaced By: N000933006151
24
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
32
WASHER COMPRESSED AIR LINE TO BRACKET
32
WASHER , Replaced By: N009021006208
40
NUT BALL PIVOT TO LEVER
48
CLAMP SAFETY VALVE AT BRACKET
48
CLAMP , Replaced By: N916016038201
56
SCREW PUMP TO BRACKET
56
SCREW , Replaced By: N304017006016
64
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
80
HOSE DE-AERATION 7X11 MM, ORDER BY THE METER
88
GROMMET CAB ROOF
96
CLAMP
104
SCREW COVER PLATE TO COVER PLATE M 6 X 12
104
SCREW , Replaced By: N304017006018
112
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
120
NUT BALL PIVOT TO LEVER
128
BRACKET BATTERY MASTER SWITCH
136
SCREW BRACKET TO CROSS CONNECTION STRUT
136
SCREW , Replaced By: N304017008034
144
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
152
NUT , Replaced By: N304032008006
160
SCREW BRACKET TO CROSS CONNECTION STRUT
160
SCREW , Replaced By: N304017008034
168
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
176
NUT , Replaced By: N304032008006
999
CLAMPING PIECE FROM THERMOSTAT OIL LINE TO TRANSMISSION OUTLET OIL LINE 900 MM
999
CLAMPING PIECE CABLE CONNECTOR
999
