Поз.
Артикул
Описание
402
TRANSMISSION CASE COVER (SHIFTER COVER), FROM CHASSIS 654647 TRANSMISSION S 6-80 FROM TRANSMISSION 005443 FOR USE WITH "S" TRANSMISSION
402
TRANSMISSION CASE COVER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO TRANSMISSION 089542, Replaced By: A0002611719
407
GASKET LATERAL, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
407
GASKET , Replaced By: A0002650280
407
GASKET , Replaced By: A3432650679
408
SPRING WASHER STEERING COLUMN BRACKET TO CAB
409
SCREW MOUNTING AND RAIL TO LEAF SPRING
410
SCREW STRAP TO BRACKET
411
SCREW CLUTCH TO FLYWHEEL
412
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
412
SCREW , Replaced By: N304014010004
413
SCREW , Replaced By: N304017010055
413
SCREW , Replaced By: N304017010050
414
GASKET LATERAL
414
GASKET , Replaced By: A0002685580
415
COVER LATERAL
416
SPRING WASHER ALTERNATOR CONNECTION D+
417
SCREW BRACKET TO TAIL LAMP BRACKET
418
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
419
COVER , Replaced By: A0009977535
419
PLUG , Replaced By: A0009973435
419
PLUG , Replaced By: A0009977535
419
PLUG , Replaced By: A3529970032
419
SCREW PLUG BELL HOUSING
420
UNIT IDENTIFICATION PLATE , Replaced By: A0005842224
420
UNIT IDENTIFICATION PLATE , Replaced By: A0005843024
420
UNIT IDENTIFICATION PLATE
423
LOCK PLATE SHIFT CASE
425
DETENT , Replaced By: A0002601873
426
SWITCH FRONT AXLE DRIVE INDICATOR, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
427
FLANGE FRONT AXLE DRIVE INDICATOR, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
428
SPRING WASHER ALTERNATOR CONNECTION D+
429
SCREW BRACKET TO TAIL LAMP BRACKET
438
COVER , Replaced By: A0002680134
438
BEARING COVER , Replaced By: A0002680634
438
BEARING COVER SHIFTING DOME
440
SPRING WASHER , Replaced By: N000137008212
440
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
441
SCREW , Replaced By: N000933008337
441
SCREW , Replaced By: A0099900101
441
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
442
SEAL RING SHIFTING DOME TO 000 268 12 01
444
VALVE BREATHER, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
445
NEEDLE BEARING REAR DRIVE SHAFT
446
BUSHING SHIFTING DOME,TOP
447
SEAL RING SHIFTING SHAFT
448
BOOT SHIFTING SHAFT
449
SCREW PLUG
451
COVER SHIFT CASE,BOTTOM
451
COVER SHIFT CASE,BOTTOM
454
GASKET , Replaced By: A0002685180
454
GASKET SHIFT CASE,TOP AND BOTTOM
455
COVER SHIFT CASE,SIDE, FROM CHASSIS 654647 TRANSMISSION S 6-80
456
GASKET CASE,REAR
457
SPRING WASHER STEERING COLUMN BRACKET TO CAB
458
SCREW END PIECE TO EXHAUST PIPE M 10X25
468
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002683974
468
PIN SHIFT CASE,BOTTOM
469
SPRING SHIFT CASE
470
SHAFT SHIFT CASE
471
EXPANSION PLUG , Replaced By: A0002611933
471
COVER , Replaced By: A0009971120
471
EXPANSION PLUG HOUSING,BOTTOM
472
SHAFT , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0002605038
472
SHAFT GEARSHIFT MECHANISM
480
ROLLER SHIFTING SHAFT
482
SHIFTING SEGMENT , Replaced By: A0002680246
482
SHIFTING SEGMENT , Replaced By: A0002680446
482
SHIFTING SEGMENT SHIFTING SHAFT
483
FOLLOWER TOP
490
FOLLOWER SHIFTING SHAFT
491
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
492
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
493
SPACER RING SHIFTING SHAFT
499
LOCK SHIFTING SHAFT
500
SPACER WASHER , Replaced By: A0002681552
500
SPACER WASHER SHIFTING SHAFT
510
SPRING SHIFTING SHAFT
513
SPRING SHIFTING SHAFT,10/20879180, 50/60880936
530
JOINT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002684889
530
JOINT SHIFTING SHAFT,TOP
531
NUT , Replaced By: A0002680472
531
NUT , Replaced By: N913004010010
531
NUT , Replaced By: N910113010002
531
HEXAGON NUT
536
NUT , Replaced By: N308673014001
536
NUT BRACKET TO SIDE MEMBER,K 035196
543
CONNECTOR , Replaced By: A0002680828
543
CONNECTOR SHIFTING TUBE TO SHIFT LEVER
550
NUT , Replaced By: N910113010000
550
NUT STRAP TO BRACKET
550
NUT STRAP TO BRACKET
551
JOINT , Replaced By: A0002684789
551
JOINT , Replaced By: A0002686189
551
JOINT TOP
552
NUT STRAP TO SUPPORT,5 149419
553
SHIFTING ROD , Replaced By: N900331012339
553
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLY
555
NUT STRAP TO SUPPORT,5 149419
556
JOINT , Replaced By: A0002684689
556
JOINT , Replaced By: A0002686289
556
JOINT BOTTOM
570
BRACKET TRANSMISSION
999
SCREW FUEL TANK TO SUPPORT
999
GASKET ,290281, Replaced By: A0002642980, +001A0002642111
999
RUBBER MOUNTING CLUTCH END, UP TO IDENT NO.004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
999
SEAL RING , Replaced By: A0079972247
999
SEAL RING , Replaced By: A0079972347
999
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
999
LOCK , Replaced By: N900055045300
999
999
GASKET
999
LOCK , Replaced By: A3859941032
999
GEAR , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002622112
