Поз.
Артикул
Описание
5
RADIATOR (CHARGING AIR INTERCOOLER)
8
BRACKET (CHARGING AIR INTERCOOLER)
11
BRACKET (CHARGING AIR INTERCOOLER),092397
11
BRACKET (CHARGING AIR INTERCOOLER),092396
12
SCREW SPEED SENSOR TO REAR AXLE
12
SCREW , Replaced By: N910143008000
13
NUT , Replaced By: N913023010002
26
NUT BRACKET TO SIDE MEMBER M12X1.5
29
HOSE AIR INTAKE PIPE TO ENGINE
32
HOSE CONNECTION OF CHARGING AIR PIPES
32
HOSE CHARGING-AIR-INTERCOOLER/TURBOCHARGER CONNECTION, Replaced By: A0015017982
32
HOSE CONNECTION OF CHARGING AIR PIPES
32
CHARGE AIR HOSE FROM CHARGING AIR INTERCOOLER TO ENGINE
32
CHARGE AIR HOSE. HOSE (ACCORDION TUBE) FROM AIR INTAKE PIPE TO INTAKE FITTING
35
CLAMP CONNECTION OF CHARGING AIR PIPES
35
CLAMP , Replaced By: N000000000675
35
CLAMP CONNECTION OF CHARGING AIR PIPES
35
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE 100-120X13 MM
35
CLAMP CONNECTION OF CHARGING AIR PIPES
45
RUBBER BUFFER COVERING TO FRAME
48
RUBBER MOUNTING AIR CLEANER TO SUBSTRUCTURE
49
RUBBER MOUNTINGM8
84
SENDER UNIT
86
BRACKET (CHARGING AIR INTERCOOLER),092397
89
BRACKET (CHARGING AIR INTERCOOLER),092397
92
SCREWM 10X20
95
AIR BAFFLE AT CHARGING AIR INTERCOOLER,092397
98
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
98
SCREW CLAMP MOUNTING M 6X16
98
SCREW , Replaced By: N914146006102
101
NUT , Replaced By: N913023006001
101
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
104
AIR BAFFLE AT CHARGING AIR INTERCOOLER,092397
107
SEAL AT CHARGING AIR INTERCOOLER,092397
113
SEAL AT CHARGING AIR INTERCOOLER,092397
116
SEAL AT CHARGING AIR INTERCOOLER,092397
119
SEAL AT CHARGING AIR INTERCOOLER,092397
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
LINE CHARGING AIR LINE
999
RADIATOR (CHARGING AIR INTERCOOLER)
999
RADIATOR (CHARGING AIR INTERCOOLER)
999
RUBBER MOUNTING FASTENING OF LINES AND HOSES
999
AIR INTAKE PIPE CHARGING AIR LINE
