Поз.
Артикул
Описание
205
FOLDING SEAT LEFT DOUBLE FOLDING SEAT, W/O BELT
226
SEAT FRAMEWORKTO A6289300005 / A6289300105, .......I.......INO.7E87I.......I II
230
SUPPORT SEAT FRAMEWORK
241
PANELLING BACKREST
245
ROD
247
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
248
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
260
GAS PRESSURE SPRING BACKREST
281
BACKRESTTO A6289300005 / A6289300105
285
COVERING RIGHT, .......INO.7E86I.......I.......I II
285
COVERING LEFT, .......INO.7E86I.......I.......I II
301
COVER , STATE COLOR WHEN ORDERING
311
PAD
315
ANGLE
320
NUT , Replaced By: N913023006001
325
HEXALOBULAR BOLT FASTENING RADIO SET 4X12
330
TAPPING SCREW4,2X16
335
BALL PIVOT ACCELERATOR PEDAL,4 859026
351
SEAT CUSHIONTO A6289300005 / A6289300105
360
NUT , Replaced By: N913023006001
360
NUT BRACKET TO FIRE WALL
365
HEXALOBULAR BOLT FASTENING RADIO SET 4X12
370
BALL PIVOT ACCELERATOR PEDAL,4 859026
375
TAPPING SCREW CONTROL UNIT TO FIRE WALL
380
BUFFER , Replaced By: A2019880511
391
SEAT CUSHIONTO A6289300621
396
COVER , STATE COLOR WHEN ORDERING
401
PAD
410
BUSHING
416
SEAT CUSHION FRAME
421
COVERING
431
SEAT FRAMEWORKTO A6289304105
441
SEAT FRAMEWORKTO A6289304105
445
RIVET COVERING TO BODY
455
PLATE
457
MOUNTING STRIP80X30X20
480
SCREW DOUBLE OCCUPANCY SEAT TO SIDE PANEL AND TO FLOOR M10X18MM
490
SLIDE
495
COVERING
