Поз.
Артикул
Описание
50
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
50
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
53
BRAKE HOSE FROM FITTING TO REAR AXLE ONE-CIRCUIT PISTON CYLINDER 450 MM
56
CLAMP HOSE TO FITTING
59
UNION NUT LINE CONNECTION
62
GLAND LINE CONNECTION
65
BUSHING COMPRESSED-AIR-LINE PLUG-CONNECTION
68
FITTING DIAPHRAGM CYLINDER,CONNECTION:
68
FITTING DIAPHRAGM CYLINDER,CONNECTION:
68
FITTING LEFT AND RIGHT BRAKE HOSES
71
FITTING DIAPHRAGM CYLINDER,CONNECTION:
74
UNION NUT LINE CONNECTION, Replaced By: N000000006239
74
UNION NUT LINE CONNECTION
77
GLAND , Replaced By: A0019901967
77
SEAL CONE LINE CONNECTION
80
CLAMP HOSE TO FITTING AND TO OIL TANK
80
CLAMP HOSE TO FITTING AND TO OIL TANK
92
TEST CONNECTION
92
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
92
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
92
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
95
PLUG
98
LOOM TIE LINE MOUNTING
98
LOOM TIE LINE MOUNTING 280 MM
131
VALVE (SAFETY VALVE)
134
WASHER THROTTLE VALVE
137
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
140
SEAL RING LINE CONNECTION
320
VALVE P.T.O.
323
FITTING 3/2-WAY VALVE,CONNECTION: "20"
326
SCREW PLUG , Replaced By: N000908012009
326
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
329
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
329
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
332
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
335
HOLLOW SCREW HEATING CONNECTION
338
SEAL RING LINE CONNECTION
341
WASHER
359
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
362
WASHER , Replaced By: N000433015005
362
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
365
COTTER PIN STRAP TO SUPPORT
368
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
371
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
374
ADAPTER FITTING PASSAGE OF LINE THRU SIDE MEMBER,5 395033
377
FITTING , Replaced By: A0019902771
377
ELBOW FITTING DELIVERY LINE TO PUMP
380
NUT BRACKET TO SIDE MEMBER
383
LOCK BRAKE HOSE TO ANGLE
386
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
389
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
389
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
392
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
392
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
407
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SCREW PIPE CLAMP
999
SCREW PARTICLE FILTER
999
SCREW , Replaced By: N304017008021
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
FITTING , Replaced By: A0029905971
