Поз.
Артикул
Описание
7
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
14
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
14
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
21
PLASTIC PIPE RISING PIPE 4X6 MM
21
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
28
UNION NUT
35
SEAL CONE
35
GLAND , Replaced By: A0019901667
42
SLEEVE LEAK LINE
49
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
49
BANJO UNION , Replaced By: N000000000364
49
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
56
LOCK RING LINE CONNECTION
56
SEAL RING , Replaced By: A0009940747
63
LOCK LINE CONNECTION
63
LOCK , Replaced By: A0009945448
70
SCREW. UNION SCREW LINE CONNECTION
70
SCREW. UNION SCREW , Replaced By: A0009973734
77
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
77
ELBOW FITTING , Replaced By: A0049905371
91
RESERVOIR AIR RESERVOIR
91
RESERVOIR , Replaced By: A0034320201
98
FITTING AIR RESERVOIR,CONNECTIONS: "10,20"
105
O-RING CHECK VALVE TO AIR RESERVOIR
112
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
112
THRUST RING CHECK VALVE TO AIR RESERVOIR
119
HOLLOW SCREW HEATING CONNECTION
126
SEAL RING LINE CONNECTION
133
FITTING AIR RESERVOIR,CONNECTION: "26", NOT USED
140
BRACKET AT VALVE
147
VALVE (CHECK VALVE)
154
SEAL RING LINE CONNECTION
161
VALVE DRAIN, Replaced By: A0004322107
161
VALVE. DRAIN VALVE DRAIN
161
VALVE. DRAIN VALVE DRAIN
161
VALVE DRAIN, Replaced By: A0004322107
161
VALVE DRAIN, Replaced By: A0004322407
168
RING DRAIN VALVE TO 000 432 08 07, NOT USED
175
O-RING CHECK VALVE TO AIR RESERVOIR
182
THRUST RING CHECK VALVE TO AIR RESERVOIR
182
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
189
VALVE (3/2-WAY SOLENOID VALVE) EKS
203
HOLLOW SCREW HEATING CONNECTION
203
HOLLOW SCREW HEATING CONNECTION
210
SEAL RING LINE CONNECTION
210
SEAL RING LINE CONNECTION
217
SCREW VALVE TO BRACKET M 8X55
217
SCREW , Replaced By: N304017008043
224
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
224
NUT , Replaced By: N913004008001
238
SCREW END PIECE TO EXHAUST PIPE M 10X25
245
SCREW PIPE CLAMP
245
SCREW , Replaced By: N304017008021
252
SCREW TO PLUG THE FREE CONNECTIONS
266
NUT STRAP TO BRACKET
266
NUT , Replaced By: N910113010000
273
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
273
NUT , Replaced By: N913004008001
280
SEAL RINGBOSCH
287
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
294
FITTING LINE CONNECTION
301
SEAL RING FUEL LINE TO FEED PUMP
308
HOLLOW SCREW FUEL LINE TO FEED PUMP
308
HOLLOW SCREW FUEL LINE TO FEED PUMP
308
HOLLOW SCREW , Replaced By: N915036010108
315
SEAL RING FUEL LINE TO FEED PUMP
315
SEAL RING FUEL LINE TO FEED PUMP
322
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
329
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
336
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
336
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
343
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
343
HOLLOW SCREW LINE CONNECTION
357
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
357
SEAL RING LINE CONNECTION
371
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
378
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
385
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
392
LOOM TIE LINE MOUNTING 280 MM
999
NUT EXHAUST PIPE TO SIDE MEMBER
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
PROTECTIVE CAPWABCO
999
ELBOW FITTING HOSE WIDTH, 4 MM,TO M 22
999
GASKET KITKNORR
999
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10",TO M 22, VOSS 232
999
SEAL RINGWABCO
999
SEAL RINGBOSCH
999
CONNECTOR
999
CONNECTOR
999
BRACKET SHUTTLE VALVE
999
BRACKET 3/2-WAY VALVE
999
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
999
SCREW TWO-WAY VALVE TO BRACKET
999
NUT TWO-WAY VALVE TO BRACKET
