Поз.
Артикул
Описание
5
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 16
5
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 16
5
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
5
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
5
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
10
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
12
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
12
ELBOW FITTING HOSE WIDTH, 6 MM,TO M 22
15
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
20
SCREW. UNION SCREW LINE CONNECTION
20
SCREW. UNION SCREW , Replaced By: A0009973734
25
SCREW. UNION SCREW LINE CONNECTION
30
LOCK LINE CONNECTION
30
LOCK , Replaced By: A0009945448
35
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
40
LOCK RING LINE CONNECTION
40
SEAL RING , Replaced By: A0009940747
45
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
50
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
50
REPAIR KIT , Replaced By: A0309971748
55
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
58
BRAKE VALVE (TRAILER CONTROL VALVE),TWO-LINE BRAKE "WABCO"
60
BRAKE VALVE (TRAILER CONTROL VALVE),ONE-LINE BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
62
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
62
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
65
BRACKET TRAILER CONTROL VALVE TO APPARATUS SUPPORT
70
BRACKET
70
BRACKET TRAILER CONTROL VALVE TO BRACKET
70
BRACKET TRAILER CONTROL VALVE TO BRACKET
70
BRACKET TRAILER CONTROL VALVE TO BRACKET
70
BRACKET TRAILER CONTROL VALVE,5 298636
70
BRACKET TRAILER CONTROL VALVE,5 298636
75
BRACKET TRAILER CONTROL VALVE,5 298636
75
BRACKET TRAILER CONTROL VALVE,5 298636
76
BRACKET TRAILER CONTROL VALVE,5 747183
76
BRACKET TRAILER CONTROL VALVE,5 747183
76
BRACKET TRAILER CONTROL VALVE,5 747183
76
BRACKET TRAILER CONTROL VALVE,5 747182
77
BRACKET BRACKET TO TRAILER CONTROL VALVE,5 720506
78
BRACKET BRACKET TO TRAILER CONTROL VALVE,5 720507
80
NUT STRAP TO BRACKET
80
NUT , Replaced By: N910113010000
85
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
85
SCREW SUPPORT TO FENDER
85
SCREW SUPPORT TO FENDER
85
SCREW , Replaced By: N304017008018
85
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
85
SCREW , Replaced By: N304017008027
85
SCREW END PIECE TO EXHAUST PIPE M 10X25
85
SCREW BRACKET TO CROSS CONNECTION STRUT
85
SCREW , Replaced By: N304017008034
85
SCREW END PIECE TO EXHAUST PIPE M 10X25
85
SCREW END PIECE TO EXHAUST PIPE M 10X25
85
SCREW BRACKET TO SIDE MEMBER
85
SCREW , Replaced By: N304017010002
87
SCREW END PIECE TO EXHAUST PIPE M 10X25
87
SCREW END PIECE TO EXHAUST PIPE M 10X25
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
90
NUT , Replaced By: N913004008001
92
NUT STRAP TO BRACKET
92
NUT STRAP TO BRACKET
92
NUT STRAP TO BRACKET
92
NUT STRAP TO BRACKET
92
NUT , Replaced By: N910113010000
93
T-FITTING SHUTTLE VALVE TO BRAKE CYLINDER
93
T-FITTING SHUTTLE VALVE TO BRAKE CYLINDER
95
T-FITTING LINE CONNECTION
95
T-FITTING LINE CONNECTION
95
T-FITTING CHECK VALVE TO RELAY VALVE
95
T-FITTING LINE CONNECTION
100
NUT CHECK VALVE TO AIR RESERVOIR
100
NUT CHECK VALVE TO AIR RESERVOIR
105
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
108
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
110
O-RING CHECK VALVE TO AIR RESERVOIR
110
O-RING CHECK VALVE TO AIR RESERVOIR
110
O-RING CHECK VALVE TO AIR RESERVOIR
111
THRUST RING CHECK VALVE TO AIR RESERVOIR
111
THRUST RING CHECK VALVE TO AIR RESERVOIR
111
THRUST RING CHECK VALVE TO AIR RESERVOIR
111
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
112
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
113
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
114
SCREW. UNION SCREW LINE CONNECTION
114
SCREW. UNION SCREW LINE CONNECTION
114
SCREW. UNION SCREW LINE CONNECTION
115
FITTING LINE CONNECTION
117
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
117
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
120
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
120
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
125
VALVE (PRESSURE LIMIT VALVE)
125
FITTING LINE CONNECTION
125
FITTING LINE CONNECTION
125
VALVE (PRESSURE RELIEF VALVE)
125
VALVE (PRESSURE LIMIT VALVE)
130
REPAIR KIT PRESSURE RELIEF VALVE
130
REPAIR KIT , Replaced By: A0004200871
130
REPAIR KIT PRESSURE LIMIT VALVE
135
BRACKET PRESSURE RELIEF VALVE
135
BRACKET PRESSURE RELIEF VALVE
140
SCREW VALVE TO SIDE MEMBER,5 295723
140
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
140
SCREW , Replaced By: N304014008001
140
SCREW VALVE TO SIDE MEMBER,5 295723
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
NUT , Replaced By: N913004008001
146
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "21,22"
146
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "21,22"
147
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
147
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
147
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
150
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
150
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
150
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
160
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
160
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
160
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
161
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
161
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
162
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
163
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
163
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
164
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
164
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
165
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
166
SCREW. UNION SCREW LINE CONNECTION
167
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
167
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
168
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
168
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
169
BRAKE LINE COUPLING
175
BRAKE LINE COUPLING AT REAR CROSS MENBER
175
BRAKE LINE COUPLING AT REAR CROSS MENBER
175
BRAKE LINE COUPLING AT REAR CROSS MENBER
190
SEAL RINGTO 000 429 75 30
200
BRACKET AT FRAME
200
BRACKET AT FRAME
202
BRACKET BRAKE LINE COUPLING TO BRACKET,K 119510
205
FITTING BRAKE LINE COUPLING TO REAR CROSS MEMBER
205
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
210
O-RING CHECK VALVE TO AIR RESERVOIR
215
THRUST RING CHECK VALVE TO AIR RESERVOIR
215
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
220
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
225
TEST CONNECTION
225
TEST CONNECTION
225
TEST CONNECTION
225
TEST CONNECTION
225
TEST CONNECTION BULKHEAD FITTING
225
TEST CONNECTION , Replaced By: A0004313031
230
INSULATING HOSE LENGTH AVAILABLE: 370 MM
235
BRACKET LINE TO SIDE MEMBER, NOT USED
240
SCREW JUNCTION BOX TO BRACKET
245
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
245
NUT , Replaced By: N913004008001
250
LOOM TIE LINE MOUNTING 280 MM
250
RUBBER BUFFER LINE MOUNTING
999
REPAIR KIT BRAKE LINE COUPLING TO 000 429 68 30
999
VALVE CONEBOSCH
999
COVERWABCO
999
T-FITTING HOSE WIDTH, 9 MM,TO M 22
999
REPAIR KITKNORR
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
LOOM TIE LINE MOUNTING
999
REPAIR KITWABCO
999
SUPPORT (STEP BRACKET),AT APPARATUS SUPPORT
999
SUPPORT BRAKE LINE COUPLINGS
999
BRACKET TRAILER CONTROL VALVE
999
BRACKET COMPRESSED AIR PIPING
999
THREADED SLEEVE BRACKET TO TRAILER CONTROL VALVE
