Поз.
Артикул
Описание
5
AIR CLEANER
5
AIR CLEANER
17
FILTER ELEMENT AIR CLEANER
17
FILTER ELEMENT AIR CLEANER
23
SEAL RING AIR CLEANER ELEMENT
26
WASHER FELT
29
NUT
35
GASKET AIR CLEANER BOWL
38
FASTENER
71
NUT SUPPORT TO SIDE MEMBER
74
BRACKET AIR CLEANER,FRONT LEFT
74
BRACKET , Replaced By: A6555282540
74
BRACKET AIR CLEANER,FRONT RIGHT
74
BRACKET , Replaced By: A6555282640
77
BRACKET AIR CLEANER,FRONT LEFT
77
BRACKET AIR CLEANER,REAR RIGHT
89
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
89
SCREW AIR CLEANER SUPPORT TO SIDE MEMBER, FRONT,K 000844
89
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
89
SCREW , Replaced By: N308676014020
92
NUT SUPPORT TO SIDE MEMBER
92
NUT COMBINATION CYLINDER TO BEARING BRACKET
92
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
92
NUT BRACKET TO SIDE MEMBER
92
NUT , Replaced By: N910113014001
107
HOSE FROM PICO AIR CLEANER TO INTAKE MANIFOLD AT ENGINE
119
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
119
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
119
CLAMP , Replaced By: N000000000678
128
BOOT
128
BOOT FROM AIR CLEANER TO INTAKE FITTING,5 946572
134
CLAMP BOOT TO INTAKE PIPE
137
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER,5 946572
140
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
