Поз.
Артикул
Описание
5
HOSE FROM RADIATOR TO THERMOSTAT
8
CLAMP HOSE 70-90X13 MM
8
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
8
CLAMP , Replaced By: A0059972990
8
CLAMP , Replaced By: N000000000674
11
HOSE FROM RADIATOR OUTLET TO WATER PUMP
14
PIPE ELBOW AT WATER PUMP,5 510518
15
PIPE ELBOW FOR SCREW FITTING
17
SCREW BRACKET TO FRAME SIDE MEMBER
18
PIN PIPE ELBOW TO BRACKET,K 023462
19
SPACER RING PIPE ELBOW TO BRACKET,K 023462
20
NUT STRAP TO BRACKET
20
NUT , Replaced By: N910113010000
23
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
26
CLAMP HOSE 70-90X13 MM
26
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
26
CLAMP , Replaced By: A0059972990
26
CLAMP , Replaced By: N000000000674
29
CONNECTOR FOR SCREW FITTING
32
GASKET CONNECTOR
32
GASKET CONNECTOR, Replaced By: A0002011280
32
GASKET CONNECTOR, Replaced By: A0002011180
32
GASKET CONNECTOR, Replaced By: A0002011080
32
GASKET , Replaced By: A4422010480
35
SCREW SUPPORT TO SUPPORT
35
SCREW END PIECE TO EXHAUST PIPE M 10X25
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
38
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
60
LINE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
60
LINE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
61
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
62
CLAMP
62
CLAMP
62
CLAMP , Replaced By: N000000000670
63
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
63
CLAMP , Replaced By: N000000000667
64
SCREW PUMP TO BRACKET
64
SCREW , Replaced By: N304017006016
65
NUT PUMP TO BRACKET
65
NUT , Replaced By: N913004006001
68
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
71
GASKET. SEAL DE-AERATION PIPE TO ENGINE
74
SCREW END PIECE TO EXHAUST PIPE M 10X25
86
HOSE DE-AERATION PIPE TO EXPANSION TANK
95
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
95
CLAMP , Replaced By: N000000000667
999
HOSE , Replaced By: A4355060535
999
WASHER , Replaced By: A1894660751
