Поз.
Артикул
Описание
100
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
100
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
102
SHIFTING TUBE (TELESCOPIC TUBE)
102
SHIFTING TUBE (TELESCOPIC TUBE)
104
ROD END HYDRAULIC RELEASE
107
SEAL RING HYDRAULIC RELEASE
110
PAWL SHIFTING ROD,5 443048
113
BUSHING PAWL TO ROD END,5 443048
113
BUSHING PAWL TO ROD END,5 443048
116
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
119
ROUND CORD RING. SEAL RING ROD END
122
SPRING ROD END
125
SPRING ROD END
128
SCREW SHIFTING ROD TO SHIFT LEVER
128
SCREW , Replaced By: N000933010192
131
NUT , Replaced By: N910113010000
131
NUT STRAP TO BRACKET
137
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
137
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
140
SEAL RING PISTON RINGS WABCO
143
SEAL RING SCREW FITTING WABCO
146
SEAL RING OUTSIDE WABCO
149
SPRING WASHER SHIFTING CYLINDER TO YOKE
152
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
155
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
158
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
158
COTTER PIN LEVER TO ROD
161
WASHER BETWEEN THE SHIFTING RODS
168
SHIFTING ROD REAR
168
ROD REAR
168
SHIFTING ROD REAR
168
ROD REAR
170
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
173
NUT STRAP TO BRACKET
173
NUT , Replaced By: N910113010000
176
CLAMPING PIECE SHIFTING ROD TO TRANSMISSION
188
JOINT SHIFTING ROD TO TRANSMISSION
188
JOINT SHIFTING ROD TO TRANSMISSION
190
SCREW CONNECTOR TO REAR SHIFTING ROD
190
SCREW , Replaced By: N304017010047
192
SCREW SHIFTING ROD TO TRANSMISSION
194
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
197
NUT
197
NUT , Replaced By: N304032008006
200
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
203
ROUND CORD RING. SEAL RING ROD END
206
SCREW , Replaced By: N000933010192
206
SCREW SHIFTING ROD TO SHIFT LEVER
209
SPRING WASHER LEVER TO BRACKET
209
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
212
NUT , Replaced By: N910113010000
212
NUT STRAP TO BRACKET
999
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.00 MM
999
SWITCH , Replaced By: A0005459009
999
SWITCH , Replaced By: A0015451109
999
SWITCH , Replaced By: A0015452709
999
SWITCH TORQUE REDUCER
999
SWITCH GEAR CLUSTER INDICATION
999
SEAL RING LEVER BEARING
999
CONNECTOR REAR SHIFTING ROD TO CONNECTOR
999
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
999
PIN SHIFTING ROD TO JOINT
999
ROD REAR
999
ROD REAR
999
EXPANSION PLUG ROD END
999
SCREW CONNECTOR TO REAR SHIFTING ROD
999
SEAL RING SWITCH TO CASE COVER
