Поз.
Артикул
Описание
5
BRAKE BOOSTER ASSEMBLY
5
BRAKE BOOSTER ASSEMBLY , Replaced By: A6614304030
6
BRAKE BOOSTER ASSEMBLY BRAKE BOOSTER
7
VALVEK 00000-00620
8
SEAL RINGK 00000-00621
9
CUPK 00000-00622
10
RESERVOIR
10
RESERVOIR , Replaced By: A6614303102
15
COVER
18
SEAL RING
20
BRAKE MASTER CYLINDER
25
PIN BRAKE BOOSTER ASSEMBLY TO PEDAL K 30460-05000
30
LOCKK 95314-10001
35
GASKET BRAKE BOOSTER ASSEMBLY TO SUPPORT K 48525-05000
40
NUT COVERING TO RAIL
42
BRACKET VACUUM LINE MOUNTING
45
LINE VACUUM LINE TO INTAKE MANIFOLD M 161
45
LINE VACUUM LINE TO INTAKE MANIFOLD M 161
50
VALVE LOAD-DEPENDING BRAKE
55
COMBINATION BOLTM 95907-0816D M 8X16
60
LEVER
65
CLIP LEVER TO SHAFT,P 012148
70
SPRING BRAKE POWER REGULATOR TYP"C"SA 088911/01
70
SPRING , Replaced By: A6614303793
75
ROD BRAKE PRESSURE REGULATION,REAR AXLE 138 MMSA 088918/02,024524
75
ROD BRAKE PRESSURE REGULATION,REAR AXLE 118 MM,024523
80
LOCK WASHER RAIL TO BATTERY SUPPORT
85
NUT CONTROL ROD M 92064-0800D
