Поз.
Артикул
Описание
188
TANK COOLING WATER EXPANSION
191
SIGHT GLASSTO 357 500 10 49
194
SIGHT GLASSTO 357 500 10 49
197
SEAL RINGTO 357 500 10 49
200
SEAL RINGTO 357 500 10 49
203
SEAL RING WATER LEVEL SENSOR
206
RADIATOR CAP FILLER NECK
209
RADIATOR CAP FILLER NECK
212
GASKET O.D., 52 MM
215
GASKET O.D., 37 MM
218
HOSE OVERFLOW TO 357 500 10 49
221
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
224
STRAP EXPANSION TANK TO BRACKET
227
STRAP EXPANSION TANK TO BRACKET
230
BOTTOM EXPANSION TANK
230
BOTTOM EXPANSION TANK
233
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
233
CLAMP HOSE TO FITTING AND TO OIL TANK
236
PIN CLAMP TO BATTERY CASE,PB004444
237
SHIM EXPANSION TANK TO BRACKET
237
RUBBER STRIP , Replaced By: A3825047984
239
SCREW STEERING SHAFT BEARING TO CAB M 8X20
242
NUT
245
COTTER PIN CLAMP TO BATTERY CASE,PB004444
248
WASHER TRAILER PLUG SOCKET TO BRACKET
248
WASHER PLUG SOCKET TO BRACKET
251
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
999
999
999
ANGLE FROM BUBBLE SEPARATOR TO ENGINE,D 078480
999
BRACKET LINE TO RETARDER
999
BRACKET LINE TO RETARDER
999
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
999
