Поз.
Артикул
Описание
5
AIR CLEANER (PAPER AIR CLEANER) MANN & HUMMEL
5
AIR CLEANERKNECHT,5 451580
11
FILTER ELEMENT AIR CLEANER MANN & HUMMEL
22
FILTER BOWL LOWER PART MANN & HUMMEL,5 451580
22
FILTER BOWL ,5 451580
26
NUT
26
NUT SWITCH TO FLOOR PLATE
29
GASKET ,5 451580
29
GASKET AIR CLEANER BOWL MANN & HUMMEL
32
FASTENER AIR CLEANER BOWL MANN & HUMMEL
32
FASTENER ,5 451580
38
BRACKET ,5 451580
47
SCREW , Replaced By: N308676016020
47
SCREW CONSOLE TO FRAME
56
WASHER , Replaced By: N000125017016
56
WASHER BRACKET TO FRAME
62
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
62
NUT COMBINATION CYLINDER TO BEARING BRACKET
68
WASHER , Replaced By: N000125008443
68
WASHER EXHAUST MUFFLER TO STRAP
71
NUT , Replaced By: N913004008001
71
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
71
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
74
MUFFLER (INTAKE MUFFLER)
77
RUBBER MOUNTING BRACKET TO BEARING BRACKET
80
BRACKET INTAKE MUFFLER
83
SCREW , Replaced By: N304017008021
83
SCREW PIPE CLAMP
86
WASHER , Replaced By: N000125008443
86
WASHER EXHAUST MUFFLER TO STRAP
89
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
89
NUT , Replaced By: N913004008001
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
92
RUBBER MOUNTING INTAKE MUFFLER TO BRACKET
95
SPACER TUBE PUMP TO FRAME SIDE MEMBER 12X21 MM
98
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
98
SCREW BRACKET TO SIDE MEMBER
98
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
98
SCREW , Replaced By: N304017008040
101
WASHER , Replaced By: N000125008443
101
WASHER EXHAUST MUFFLER TO STRAP
104
RETAINER INTAKE MUFFLER TO BRACKET
107
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
107
NUT , Replaced By: N913004008001
107
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
109
SCREW EXHAUST PIPE TO BRACKET
115
NUT STRAP TO BRACKET
115
NUT , Replaced By: N910113010000
128
AIR INTAKE PIPE
140
BUFFER REFRIGERANT LINE TO CAB
143
WASHER , Replaced By: N009021008213
143
WASHER BRACKET TO CAB REAR PANEL
143
WASHER BRACKET TO LEFT SIDE MEMBER
146
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
146
NUT , Replaced By: N913004008001
146
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
147
PLUG AIR INTAKE PIPE
149
BOOT AIR INTAKE
164
HOSE ,5 451580
170
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
170
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
170
CLAMP , Replaced By: A0059972990
170
CLAMP , Replaced By: N000000000675
170
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
215
HOSE FROM MUFFLER TO ENGINE
221
CLAMP , Replaced By: A0059972990
221
CLAMP , Replaced By: N000000000675
221
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
223
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
223
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
