Поз.
Артикул
Описание
5
TANK OIL
8
OIL DIPSTICK
8
OIL DIPSTICK , Replaced By: A0004660867
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER
26
BRACKET OIL TANK,5 094745
32
SCREW CENTRAL LOCK TO CAB M 10X16
47
SCREW OIL TANK TO BRACKET
50
NUT , Replaced By: N913004006001
50
NUT PUMP TO BRACKET
53
HOSE ,K 055044
56
LINE , Replaced By: A0004291601
56
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
56
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 138294
56
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
56
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 163366
59
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
59
CLAMP , Replaced By: N000000000667
62
HOSE (SUCTION LINE),FROM OIL TANK TO PUMP,5 138294
64
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 051606
64
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
64
LINE ,K 055043K 126843
66
UNION NUT LINE CONNECTION, Replaced By: N000000006243
66
NUT LINE CONNECTION
68
GLAND , Replaced By: A0019901267
70
ELBOW FITTING SUCTION LINE TO OIL PUMP
72
THRUST RING SUCTION LINE TO OIL PUMP
74
SEALING CORD SUCTION LINE TO OIL PUMP
76
NUT SUCTION LINE TO OIL PUMP
79
FITTING DELIVERY LINE TO PUMP
84
LINE ,K 055043
86
UNION NUT LINE CONNECTION
86
UNION NUT LINE CONNECTION, Replaced By: N000000006239
89
SEAL CONE LINE CONNECTION
89
GLAND , Replaced By: A0019901967
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
107
HOSE POWER-STEERING-PUMP-TO-STEERING-BOX DELIVERY LINE
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,5 138293
125
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 163366
131
NUT. UNION NUT LINE CONNECTION
134
CUTTING RING. GLAND LINE CONNECTION
137
SCREW-IN FITTING DELIVERY LINE TO STEERING,K 244309
143
FITTING DELIVERY LINE TO PUMP
146
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 163366
146
LINE12 MM, ORDER BY THE METER4 691315
149
UNION NUT LINE CONNECTION
149
UNION NUT LINE CONNECTION, Replaced By: N000000006239
152
GLAND , Replaced By: A0019901967
152
SEAL CONE LINE CONNECTION
161
HOSE ,K 055044
164
CLAMP HOSE TO FITTING AND TO OIL TANK
164
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
167
BRACKET DELIVERY AND SUCTION LINES,5 374584
170
SCREW , Replaced By: N304017010028
170
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
173
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
176
BRACKET DELIVERY AND SUCTION LINES
179
SCREW DISTRIBUTOR TO CAB
182
NUT PUMP TO BRACKET
182
NUT , Replaced By: N913004006001
189
CLAMP LINE MOUNTING
189
CLAMP OIL FILLER PIPE TO BRACKET
189
BRACKET WITH PLUG,K 130676
189
CLAMP , Replaced By: N916016015202
189
BRACKET HOSE TO OIL DIPSTICK GUIDE TUBE,K 130676
218
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
218
CLAMP CABLE HARNESS MOUNTING
218
CLAMP DELIVERY AND SUCTION LINES TO FRAME
218
CLAMP , Replaced By: N916016010211
218
CLAMP , Replaced By: N000000001045
218
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
224
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
227
NUT PUMP TO BRACKET
227
NUT , Replaced By: N913004006001
999
BULKHEAD FITTING DELIVERY LINE TO FRAME, Replaced By: N000000006392
999
FITTING IN-LINE FILTER,CONNECTION: "10",230274
999
BRACKET DELIVERY AND SUCTION LINES
999
LINE (DELIVERY LINE) FROM FITTING TO STEERING
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING,5 701910
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
999
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
999
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
999
PROTECTIVE CAP
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING
