Поз.
Артикул
Описание
5
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
5
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PRESSURE REGULATORBOSCH,241, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PRESSURE REGULATORWABCO
5
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
5
PRESSURE REGULATORKNORR
8
REPAIR KIT SEAL RING BOSCH,209
8
REPAIR KIT DIAPHRAGM PART BOSCH,209
8
REPAIR KIT PRESSURE REGULATOR WABCO
8
REPAIR KITTO 002 431 83 06, KNORR 90309
8
REPAIR KIT PRESSURE REGULATOR BOSCH,241
8
REPAIR KIT PRESSURE REGULATOR KNORR
11
SCREW REAR AXLE REGULATING SOLENOID VALVE
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
14
NUT , Replaced By: N913004008001
17
ELBOW FITTING ,5 433281
23
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
25
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
27
FITTING LINE CONNECTION
29
FITTING LINE CONNECTION
31
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
33
NUT CHECK VALVE TO AIR RESERVOIR
35
THRUST RING BUTT SCREW CONNECTION
35
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
35
THRUST RING CHECK VALVE TO AIR RESERVOIR
37
SEAL RING , Replaced By: N007603012121
37
O-RING CHECK VALVE TO AIR RESERVOIR
37
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
39
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
41
SEAL RING LINE CONNECTION
44
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
44
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
46
SCREW. UNION SCREW LINE CONNECTION
48
SCREW. UNION SCREW LINE CONNECTION
48
SCREW. UNION SCREW , Replaced By: A0009973734
50
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
52
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
52
HOSE , Replaced By: A0009872927
54
CONNECTOR BLEEDING
56
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
56
CLAMP , Replaced By: N000000000667
58
AIR DEHYDRATOR WITH PRESSURE REGULATOR BOSCH,K 126821
58
AIR DEHYDRATOR WITH PRESSURE REGULATOR KNORR,K 126821
58
AIR DRIERKNORR,5 937586
58
AIR DEHYDRATORBOSCH,5 937586
58
AIR DEHYDRATORWABCO,5 937586 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
60
AIR CLEANER COMPLETE TO BOSCH,KNORR
60
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
62
SEAL RINGWABCO
64
GASKET KIT SEAL RINGS KNORR,5 937586
64
GASKET KITWABCO
64
GASKET KITKNORR
66
REPAIR KIT PRESSURE REGULATOR KNORR,K 126821
66
REPAIR KIT PRESSURE REGULATOR BOSCH,K 126821
68
BRACKET AIR DEHYDRATOR,K 126821
68
BRACKET AIR DEHYDRATOR,5 9363655 812730
89
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
89
SCREW , Replaced By: N308676012038
89
SCREW BRACKET TO TRANSMISSION
92
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
98
SCREW , Replaced By: N308676012026
98
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
101
WASHER BRACKET TO FRAME
104
NUT SUPPORT TO SIDE MEMBER
106
FITTING AIR DEHYDRATOR
108
THRUST RING CHECK VALVE TO AIR RESERVOIR
108
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
110
O-RING CHECK VALVE TO AIR RESERVOIR
112
NUT CHECK VALVE TO AIR RESERVOIR
114
SCREW. UNION SCREW , Replaced By: A0009973734
114
SCREW. UNION SCREW LINE CONNECTION
114
SCREW. UNION SCREW LINE CONNECTION
116
CONNECTOR BLEEDING
116
CONNECTOR 90 DEG. OFFSET
999
ADAPTER FITTING PRESSURE REGULATOR,CONNECTIONS: "23,40",5 936366 - 5 9999995 812731 - 5 817421K 000001N 817422
999
HOSE , Replaced By: A0009872927
