Поз.
Артикул
Описание
9
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
9
HOSE , Replaced By: A0009872827
10
BANJO UNION , Replaced By: N915052009009
10
BANJO UNION , Replaced By: N915052009000
10
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
13
SLEEVE LINE CONNECTION
13
BUSHING , Replaced By: N915062009000
16
LOOM TIE LINE MOUNTING 280 MM
20
NIPPLE COMPRESSED AIR LINE TO SIDE MEMBER
27
LOOM TIE LINE MOUNTING
34
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
38
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
45
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
52
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
56
NUT CHECK VALVE TO AIR RESERVOIR
60
THRUST RING CHECK VALVE TO AIR RESERVOIR
60
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
64
O-RING CHECK VALVE TO AIR RESERVOIR
71
FITTING SHUTTLE VALVE,CONNECTION: "20"
75
THRUST RING CHECK VALVE TO AIR RESERVOIR
75
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
79
O-RING CHECK VALVE TO AIR RESERVOIR
82
T-FITTING RELAY VALVE,CONNECTION: "20"
86
BRACKET ,556500
86
BRACKET ,556499
93
NUT STRAP TO BRACKET
93
NUT , Replaced By: N910113010000
97
SCREW BRACKET TO SIDE MEMBER
101
NUT STRAP TO BRACKET
101
NUT , Replaced By: N910113010000
108
BRAKE LINE COUPLING , Replaced By: A0004297530
108
BRAKE LINE COUPLING AT REAR CROSS MENBER
108
BRAKE LINE COUPLING AT REAR CROSS MENBER
108
BRAKE LINE COUPLING AT REAR CROSS MENBER
109
VALVE DISCTO 000 429 48 30
110
SPRINGTO 000 429 16 30
111
GASKETTO 000 429 16 30
112
VALVE TAPPETTO 000 429 16 30
113
COVERTO 000 429 16 30,BOSCH
114
SPRINGTO 000 429 16 30
115
FITTING SHUTTLE VALVE
115
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
115
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
119
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
119
THRUST RING CHECK VALVE TO AIR RESERVOIR
123
O-RING CHECK VALVE TO AIR RESERVOIR
127
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
131
WASHER TELMA BRAKE TO SUPPORT ON SIDE MEMBER
135
NUT BRACKET TO SIDE MEMBER
142
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
149
NUT CHECK VALVE TO AIR RESERVOIR
153
THRUST RING CHECK VALVE TO AIR RESERVOIR
153
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
157
O-RING CHECK VALVE TO AIR RESERVOIR
159
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
162
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
165
SEAL RINGTO 006 997 00 72
172
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
172
THRUST RING CHECK VALVE TO AIR RESERVOIR
176
O-RING CHECK VALVE TO AIR RESERVOIR
183
BRACKET BRAKE LINE COUPLING,631163
183
BRACKET BRAKE LINE COUPLING, TO BE ADAPTED DURING ASSEMBLY
187
SCREW PIPE CLAMP
187
SCREW , Replaced By: N304017008021
191
NUT , Replaced By: N913004008001
191
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
191
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
198
BRACKET
202
SCREW PIPE CLAMP
202
SCREW , Replaced By: N304017008021
206
NUT , Replaced By: N913004008001
206
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
206
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
PIN
999
GASKETTO 003 429 22 44
999
SEAL RINGTO 000 429 75 30
999
VALVE CONEBOSCH
999
VALVE , Replaced By: A0004290782
999
VALVE , Replaced By: A0004291182
999
COVERTO 000 429 48 30
999
VALVE BODYTO 002 429 95 44
999
COVERWABCO
999
REPAIR KITKNORR
999
SPRING CAPSULETO 000 429 16 30
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
NUT END PIECE TO EXHAUST PIPE
999
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
999
SEAL CONE LINE CONNECTION
999
REPAIR KITWABCO
999
BALLTO 003 429 22 44
999
FITTING (PARTS KIT),LINE RUPTURE
999
VALVE TWO-WAY VOSS
999
FITTING , Replaced By: A0029906171
999
SEAL RINGTO 000 429 48 30
999
SEAL RINGTO 000 429 16 30
999
UNION NUT LINE CONNECTION
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
GLAND , Replaced By: A0019901967
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SNAP RINGTO 000 429 16 30
999
NUT , Replaced By: A0009903150
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
