Поз.
Артикул
Описание
92
HOSE FROM RADIATOR OUTLET TO WATER PUMP, TO BE ADAPTED DURING ASSEMBLY
95
CLAMP HOSE 70-90X13 MM
95
CLAMP HOSE 70-90X13 MM
95
CLAMP , Replaced By: N000000000674
98
LINE FEED LINE TO ENGINE
101
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
104
CLAMP HOSE FASTENING 50-70X13 MM
104
CLAMP , Replaced By: N000000000672
107
COOLING WATER PIPE FEED, FROM HOSE CONNECTION II TO THERMOSTAT
122
CLAMP REAR EXHAUST PIPE FRONT PART TO REAR PART, 000-059 UP TO CHASSIS 001048,070-091 UP TO CHASSIS 000143,100-135 UP TO CHASSIS 013837, 170-191 UP TO CHASSIS 000741
125
CLAMP , Replaced By: A9424310043
125
CLAMP , Replaced By: N000000001641
131
SCREW SUPPORT TO FENDER
131
SCREW , Replaced By: N304017008018
134
NUT , Replaced By: N913004008001
137
CONNECTOR THERMOSTAT
140
BRACKET CONNECTOR
143
SCREW PUMP TO BRACKET
143
SCREW , Replaced By: N304017006016
146
LOCK WASHER CHARGING AIR INTERCOOLER TO RADIATOR
149
SUSPENSION BRACKET TO RADIATOR
152
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
155
NUT , Replaced By: N304032008006
158
BRACKET BRACKET TO CROSS MEMBER
161
SCREW , Replaced By: N304017008021
164
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
167
NUT , Replaced By: N304032008006
170
COOLING WATER PIPE FEED, FROM TEMPERATURE REGULATOR TO RADIATOR
173
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
176
CLAMP HOSE FASTENING 50-70X13 MM
176
CLAMP , Replaced By: N000000000672
179
LINE FROM RADIATOR TO BUBBLE SEPARATOR
182
CLAMP SUCTION LINE TO CROSS MEMBER
185
SEPARATOR (BUBBLE SEPARATOR)
188
SCREW COVER PLATE TO BRACKET
191
NUT , Replaced By: N913004006001
197
HOSE RETURN, TO BE ADAPTED DURING ASSEMBLY
197
HOSE , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3015010782
200
CLAMP HOSE FASTENING 50-70X13 MM
200
CLAMP , Replaced By: N000000000672
203
LINE COOLING WATER INTAKE PIPE SOCKET
206
HOSE CONNECTION OF OIL FILLER PIPES, ORDER BY THE METER
209
CLAMP
209
CLAMP , Replaced By: N000000000671
212
COOLING WATER PIPE FROM BUBBLE SEPARATOR TO EXPANSION TANK
215
OUTLET FEED LINE TO ENGINE
218
GASKET OUTLET TO ENGINE
218
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
218
GASKET , Replaced By: N917003040006
221
SCREW , Replaced By: N304017010002
224
SCREW CLUTCH TO FLYWHEEL
227
SPRING WASHER STEERING COLUMN BRACKET TO CAB
230
HOSE FEED & RETURN LINES TO HEAT EXCHANGER EXCHANGER, TO BE ADAPTED DURING ASSEMBLY
233
CLAMP HOSE FASTENING 50-70X13 MM
233
CLAMP , Replaced By: N000000000672
233
CLAMP
233
CLAMP , Replaced By: N000000000671
236
LINE FEED,CENTRAL
245
CLAMP HOSE FASTENING 50-70X13 MM
245
CLAMP , Replaced By: N000000000672
245
CLAMP
245
CLAMP , Replaced By: N000000000671
248
HOSE COOLING WATER LINE TO PIPE SOCKET
251
BUSHING COOLING WATER LINE TO TRANSMISSION 50 MM
254
CLAMP REAR EXHAUST PIPE FRONT PART TO REAR PART, 000-059 UP TO CHASSIS 001048,070-091 UP TO CHASSIS 000143,100-135 UP TO CHASSIS 013837, 170-191 UP TO CHASSIS 000741
257
SCREW , Replaced By: N000933008134
263
NUT , Replaced By: N913004008001
266
PIPE SOCKET FEED LINE TO TRANSMISSION
269
GASKET FEED LINE TO TRANSMISSION
272
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
278
SPRING WASHER , Replaced By: N000137008212
281
PIPE SOCKET RETURN LINE TO TRANSMISSION
284
GASKET FEED LINE TO TRANSMISSION
287
SCREW , Replaced By: N304017008018
293
SPRING WASHER , Replaced By: N000137008212
296
COOLING WATER PIPE
299
HOSE COOLING WATER LINE TO PIPE SOCKET
302
HOSE RETURN LINE TO THERMOSTAT, ORDER BY THE METER
305
CLAMP
305
CLAMP , Replaced By: N000000000671
305
CLAMP HOSE FASTENING 50-70X13 MM
305
CLAMP , Replaced By: N000000000672
308
BRACKET FEED,CENTRAL
311
SPACER TUBE RETURN LINE TO BRACKET
314
CLAMP REAR EXHAUST PIPE FRONT PART TO REAR PART, 000-059 UP TO CHASSIS 001048,070-091 UP TO CHASSIS 000143,100-135 UP TO CHASSIS 013837, 170-191 UP TO CHASSIS 000741
320
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
329
NUT , Replaced By: N913004008001
332
LINE RETURN, FROM HOSE TO HOSE
335
BRACKET
338
SPACER TUBE RETURN LINE TO BRACKET
341
CLAMP REAR EXHAUST PIPE FRONT PART TO REAR PART, 000-059 UP TO CHASSIS 001048,070-091 UP TO CHASSIS 000143,100-135 UP TO CHASSIS 013837, 170-191 UP TO CHASSIS 000741
344
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
347
NUT , Replaced By: N913004008001
359
GASKET
359
GASKET FLANGE TO PUMP
362
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
362
SCREW , Replaced By: N304017008027
365
SPRING WASHER , Replaced By: N000137008212
999
