Поз.
Артикул
Описание
180
SHUT-OFF COCK
180
SHUT-OFF COCK
182
FITTING SHUTTLE VALVE,CONNECTION: "20"
184
SEAL RING LINE CONNECTION
186
BRAKE LINE COUPLING
190
SEAL RING"WABCO"
195
FITTING , Replaced By: A0019972372
195
FITTING SHUTTLE VALVE,CONNECTION: "20"
200
SEAL RING LINE CONNECTION
202
PLATE SUPPLY
204
PLATE BRAKE
205
NUT CHECK VALVE TO AIR RESERVOIR
210
THRUST RING CHECK VALVE TO AIR RESERVOIR
210
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
215
O-RING CHECK VALVE TO AIR RESERVOIR
216
BRACKET AT BRAKE LINE COUPLING
216
BRACKET SHUT-OFF COCK BRACKET
217
SCREW VALVE TO BRACKET
217
SCREW VALVE TO BRACKET, Replaced By: N304014008002
218
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
219
NUT
220
SCREW BRACKET TO TRANSMISSION
220
SCREW , Replaced By: N308676012038
220
SCREW BRACKET TO SIDE MEMBER
221
WASHER
223
WASHER RADIATOR TO RUBBER MOUNTING
223
WASHER , Replaced By: N000125010532
224
LOCK WASHER FITTING TO BRACKET
225
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
226
NUT STRAP TO SUPPORT
227
NUT BRACKET TO SUPPORT AND TO END PIECE
274
BRAKE LINE COUPLING
275
SEAL RING"WABCO"
278
SHUT-OFF COCK
278
SHUT-OFF COCK
280
NUT CHECK VALVE TO AIR RESERVOIR
282
THRUST RING CHECK VALVE TO AIR RESERVOIR
282
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
284
O-RING CHECK VALVE TO AIR RESERVOIR
286
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
290
FITTING , Replaced By: A0019972372
290
FITTING SHUTTLE VALVE,CONNECTION: "20"
295
SEAL RING LINE CONNECTION
297
NUT CHECK VALVE TO AIR RESERVOIR
300
FITTING LINE MOUNTING
302
GROMMET FITTING, 807793
305
PLATE BRAKE
307
PLATE SUPPLY
310
BRACKET , 674068-875476
315
BRACKET
325
BRACKET AT BRAKE LINE COUPLING
330
SCREW CONSOLE TO SIDE MEMBER
330
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
330
SCREW , Replaced By: N308676012012
335
LOCK WASHER FITTING TO BRACKET
340
NUT STRAP TO SUPPORT
345
WASHER
350
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
350
SCREW VALVE TO BRACKET
350
SCREW VALVE TO BRACKET, Replaced By: N304014008002
350
SCREW , Replaced By: N304017008045
350
SCREW BRACKET TO BEARING BRACKET
355
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
360
NUT
365
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
365
SCREW , Replaced By: N304014008001
370
SCREW , Replaced By: N304017008021
370
SCREW PIPE CLAMP
370
SCREW CLAMP TO BRACKET AND TO PIPE
375
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
380
NUT
385
SCREW BRACKET TO SIDE MEMBER
390
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
395
NUT BRACKET TO SUPPORT AND TO END PIECE
999
CLAMP ,K 147121, Replaced By: N000000000319
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
FITTING , Replaced By: A0009970171
999
T-FITTING , Replaced By: A0009902370
999
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
999
ANGLE JOINT DUMPER PUMP
999
SCREW , Replaced By: N000000001146
999
CONNECTION FITTING ,880809
999
NUT BALL PIVOT TO LEVER
999
COTTER PIN STRAP TO SUPPORT
999
SCREW CLAMP MOUNTING M 6X16
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
CLAMP , Replaced By: A6739950001
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: A3604300143
999
CLAMP , Replaced By: N916016008200
999
ANGLE LINE MOUNTING
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
BRACKET
999
BRACKET
999
BRACKET , Replaced By: A3184280240
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
SEAL RINGTO 000 429 16 31,4 940458
999
FITTING , Replaced By: A0029905971
999
REPAIR KITTO 001 431 56 05
999
FITTING , Replaced By: A0039978972
999
HANDLETO 000 429 16 31,4 940458
999
ELBOW FITTING , Replaced By: A0019904371
999
SCREW , 872789
999
REPAIR KITTO 000 429 14 31,5 116581
999
REPAIR KITWABCO
999
CUP , Replaced By: A0004313086
999
DIAPHRAGM , Replaced By: A0004313186
999
SEAL RINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
DISTRIBUTOR
999
ADAPTER FITTING , Replaced By: A0009970271
999
SHUT-OFF COCK , Replaced By: A0004291431
999
DIAPHRAGMTO 001 429 48 44
999
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
999
DIAPHRAGM
999
DIAPHRAGM
999
VALVE (CHECK VALVE)
999
LINE , Replaced By: A0005516256
