Поз.
Артикул
Описание
3
REAR AXLE WITH BRAKES,RATIO: 41:8, 017187
3
REAR AXLE WITH BRAKES,BRAKE DRUMS,HUBS,AND HAND BRAKE LINKAGE, RATIO: 41:8,001526-600000600025-603443
6
AXLE HOUSING , 017187
9
CYLINDRICAL PIN
12
SCREW SUPPORTING ARM TO ENGINE M 16X65
15
BRACKET SHOCK ABSORBER, 017187
18
BEARING BRACKET RIGHT, 017187
18
BEARING BRACKET LEFT, 017187
21
GREASE NIPPLE PROTECTIVE TUBE
24
PIN
27
PLUG
30
OIL COLLECTOR
33
THRUST RING LEFT
33
THRUST RING RIGHT
36
FITTING BLEEDING
39
SPACER WASHER
42
GROOVED NUT
45
LOCK PLATE
48
DRUM HUB
51
STUD
54
WHEEL MOUNTING BOLT
57
OIL COLLECTOR
60
SEAL RING , Replaced By: A0179970147
60
SEAL RING
63
TAPERED ROLLER BEARING
63
TAPERED ROLLER BEARING
63
TAPERED ROLLER BEARING
66
LOCK RING
69
TAPERED ROLLER BEARING
69
TAPERED ROLLER BEARING
69
TAPERED ROLLER BEARING
72
REAR AXLE SHAFT
75
NUT , Replaced By: N308673012002
75
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
78
SCREW PLUG BELL HOUSING
81
SCREW COLLAR
84
LOCK
87
TOOTHED WASHER LEVER TO AIR SPRING VALVE,K 186867
90
SCREW
93
SET SCREW
96
SLIDE
99
HEX. NUT. NUT
999
NUT , Replaced By: A6743560126
999
COVER , Replaced By: A6703510208
999
OIL COLLECTOR , Replaced By: A3163560082
999
NUT , Replaced By: A3853510372
999
DIFFERENTIAL SPIDER , Replaced By: A3183530020
999
COVER , Replaced By: A3183500021
999
RING GEAR AND PINION
999
RING GEAR AND PINION , Replaced By: A3183501139
999
COVER ,2 532875, Replaced By: A6703500021, +001A6703510080, +013N914112010016
999
RING GEAR AND PINION ,004804, Replaced By: A3183500739, +001A0029814101, +001N000471029000
999
REPAIR KIT , Replaced By: A3143500026
999
REAR AXLE SHAFT , Replaced By: A3143570501
999
REAR AXLE SHAFT , Replaced By: A3143570401
999
SIDE GEAR , Replaced By: A3143530715
999
SIDE GEAR ,000824, Replaced By: A3143530715, +004A3163530014
999
DIFFERENTIAL PINION , Replaced By: A3163530014
999
DIFFERENTIAL PINION ,000824, Replaced By: A3163530014, +002A3143530715
999
THRUST WASHER , Replaced By: A3143530962
999
SPHERICAL WASHER , Replaced By: A3143530224
999
SET SCREW , Replaced By: A3143530176
999
SCREW COLLAR , Replaced By: A3163530025
999
DIFFERENTIAL GEAR ,2 124259, Replaced By: A3163501423, +016A3189900001
999
RING GEAR AND PINION , Replaced By: A3163500039
999
DRUM HUB , Replaced By: A3143560202, +001A3163560082, +006A3144020071, +008A3149900105
999
PIN , Replaced By: A3523510174
999
VALVE
999
FLANGE , Replaced By: A3163500045
999
SCREW PLUG , Replaced By: A0009972632
999
SEAL RING , Replaced By: A0119977447
999
SEAL RING , Replaced By: A0019973247
