Поз.
Артикул
Описание
20
BUFFER , FOR 337 600 38 03,337 600 32 03,337 600 37 03,337 600 33 03,337 600 34 03 FOR 338 600 02 03,338 600 00 03,338 600 03 03,338 600 01 03
22
REINFORCEMENT LEFT, FOR 338 600 15 03,338 600 16 03,338 600 09 03,338 600 10 03
36
CONSOLE LEFT
42
CONSOLE STOP BUFFER, FOR 338 600 15 03,338 600 16 03,338 600 09 03,338 600 10 03
44
CONSOLE CENTRAL
46
HINGE MOUNTING , 867788
46
HINGE MOUNTING , Replaced By: A3526160030
50
INSERT POCKET CENTRAL FRONT
60
INSERT POCKET REAR LEFT, 867789
70
INSERT RAIL LEFT FRONT, 867788
75
INSERT RAIL , 867788
80
INSERT RAIL LEFT REAR, 867788
90
SPACER TUBE FRONT CORNER PILLAR TO FRONT PANEL AND TO SUBSTRUCTURE
100
PLATFORM PANEL TOP FRONT
100
PLATFORM PANEL , Replaced By: A3636370251
105
PLATFORM PANEL , Replaced By: A3636470351
120
PLATFORM PANEL TOP FRONT
120
PLATFORM PANEL , Replaced By: A3636370251
130
PLATFORM PANEL , Replaced By: A3636470351
150
HINGE , 892382
155
FASTENER
165
BRACKET TENSION CHAIN
165
BRACKET , Replaced By: A3636370114
165
BRACKET TENSION CHAIN
170
FOLDING STEP
190
RUBBER BUFFER PLATFORM SIDE AND REAR PANELS
195
GUMMIPUFFER. RUBBER BUFFER SIDE PANEL
200
BUFFER RAIL STOP
200
BUFFER , Replaced By: A3878910323
210
BRACKET FOR CHOCK
210
BRACKET , Replaced By: A3355800290
220
CLAMP CHOCK FIXTURE
230
CHAIN WITH CHAIN LOCK
250
REAR FENDER LEFT FRONT, OR RIGHT REAR, RESP.
255
REAR FENDER LEFT REAR,OR RIGHT FRONT,RESP.
260
RAIL
270
REINFORCEMENT REAR FENDER
275
SPLASH GUARD
280
BRACKET
300
CLAMP PLATFORM MOUNTING, FOR 338 600 15 03,338 600 09 03 FOR PLATFORM MODEL 338.621,624 FROM CHASSIS 741869
320
SHIM PLATFORM TO FRAME
999
SCREW TENSION CHAIN FASTENER AND HINGE TO SIDE PANEL
999
SPRING
999
WASHER BRACKET TO PROPELLER SHAFT BEARING HOUSING
999
DISK , Replaced By: A1232420366
999
BRACKET , EXHAUST STOCK OF OLD PART NUMBER UP TO CHASSIS 4 231000, Replaced By: A3828900079
999
REINFORCEMENT RIGHT, FOR 338 600 15 03,338 600 16 03,338 600 09 03,338 600 10 03
999
REINFORCEMENT LEFT
999
REINFORCEMENT RIGHT
999
CONSOLE , Replaced By: A3636160231
999
CONSOLE , Replaced By: A3636160331
999
PLATFORM , Replaced By: A3636002343
999
PLATFORM
999
CONSOLE
999
INSERT POCKET RIGHT, FOR 338 600 15 03,338 600 16 03,338 600 09 03,338 600 10 03
999
HINGE MOUNTING , Replaced By: A3826160130
999
GUIDE CENTRAL REAR
999
CONSOLE RIGHT
999
FRONT PANEL
999
FRONT PANEL
999
PLATFORM PANEL , Replaced By: A3826270151
999
SIDE PANEL , 865514
999
SIDE PANEL , 865514
999
SIDE PANEL , Replaced By: A3636302201
999
SIDE PANEL , Replaced By: A3636302301
999
SIDE PANEL , 865515
999
SIDE PANEL , 865515
999
HINGE , Replaced By: A3826370554
999
PLATFORM PANEL , Replaced By: A3636370251
999
PLATFORM PANEL LOWER PART
999
PLATFORM PANEL , Replaced By: A3636470351
999
PLATFORM PANEL TOP, 867789
999
PLATFORM PANEL TOP, 867789
999
REAR PANEL , 867788
999
REAR PANEL , 867789 892382
999
REAR PANEL , 892383
999
PLATFORM PANEL , Replaced By: A3636370651
999
PLATFORM PANEL TOP, 867789 892382
999
PLATFORM PANEL , Replaced By: A3636470351
999
PLATFORM PANEL TOP, 892383
999
INSERT RAIL RIGHT FRONT, 867788
999
INSERT RAIL REAR, 867788
999
INSERT RAIL RIGHT REAR, 808132 867788
999
INSERT RAIL LEFT FRONT, 867789
999
INSERT RAIL RIGHT FRONT, 867789
999
INSERT RAIL , 867789
999
INSERT RAIL REAR, 867789
999
INSERT RAIL LEFT REAR, 867789
999
INSERT RAIL RIGHT REAR, 867789
999
HINGE MOUNTING , 867789
999
PLATFORM PANEL UPPER PART, 867789
999
HINGE , 892383
999
SCREW REAR FENDER M 5X16
999
SCREW RUBBER BUFFER TO PLATFORM M 4X20
999
SCREW BATTERY CABLE THRU CAB FLOOR
999
SCREW
999
SCREW RUBBER BUFFER TO PLATFORM M 8X24
999
WASHER FRONT CORNER PILLAR TO FRONT PANEL AND TO SUBSTRUCTURE
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW REAR SIDE PANEL M8X50
999
SCREW FIXTURE TO PLATFORM M8X45
999
SCREW EDGING TO FLOOR M 8X10
999
SCREW PLATFORM MOUNTING M 10X75, FOR 338 600 15 03,338 600 09 03 FOR PLATFORM MODEL 338.621,624 FROM CHASSIS 741869
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW RADIATOR M 10X45
999
SCREW , Replaced By: N304017010050
999
SCREW , Replaced By: N304017006018
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010002
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW
999
SCREW , Replaced By: N308676012018
999
SCREW STRUTS TO SIDE MEMBER WITH ANGLE
999
SCREW BEARING BRACKET TO AIR-SPRING-BELLOWS SUPPORT M 12X110
999
SCREW SHOCK ABSORBER TO BRACKET M 12X1,5X180
999
SCREW REINFORCEMENT TO ROCKER PANEL
999
SCREW PROTECTIVE PLATE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017010055
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT
999
SCREW STRUT TO FRAME M 12X62
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER FITTING TO BRACKET
999
NUT PLATFORM MOUNTING
999
NUT , Replaced By: N910113012003
