Поз.
Артикул
Описание
7
SWITCH (BATTERY MASTER SWITCH)
15
SCREW BRACKET TO SIDE MEMBER
23
LOCK WASHER RAIL TO BATTERY SUPPORT
31
SWITCH (BATTERY MASTER SWITCH)
31
SWITCH (BATTERY MASTER SWITCH)
39
ELECTRIC CABLE
47
NEG. CABLE FROM BATTERY TO BATTERY MASTER SWITCH
55
NEG. CABLE FROM BATTERY TO BATTERY MASTER SWITCH, 364.101 UP TO CHASSIS 50233
63
NEG. CABLE FROM BATTERY MASTER SWITCH TO GROUND,070378
71
NEG. CABLE FROM BATTERY TO BATTERY MASTER SWITCH
79
POSITIVE CABLE FROM BATTERY TO STARTING MOTOR REVERSING SWITCH
95
NEG. CABLE FROM BATTERY TO BATTERY MASTER SWITCH, 364.101 UP TO CHASSIS 50233
103
ELECTRIC CABLE FROM STARTER CHANGE-OVER SWITCH,TERMINAL 31B,TO MASTER SWITCH,TERMINAL 31A
111
CLAMP BRAKE HOSE BRACKET
119
SHEET METAL SCREW MAIN CABLE HARNESS TO FIRE WALL
127
CLAMP WIRE CABLE TO CAB
135
SHEET METAL SCREW CABLE HARNESS MOUNTING
143
CLAMP FLEXIBLE SHAFT TO CAB
151
ELECTRIC CABLE DOOR CONTROL
159
SWITCH ABS AND ASR
167
BUTTON ABS AND ASR
175
NUT SWITCH TO APPARATUS PLATE
999
SWITCH BATTERY CUT-OFF
999
ELECTRIC CABLE FROM STARTING CHANGE-OVER SWITCH TO GROUND
999
NEG. CABLE FROM BATTERY I TO GROUND
999
NEG. CABLE FROM BATTERY TO BATTERY CHANGE-OVER SWITCH, 364.101 UP TO CHASSIS 50233
999
STARTER SWITCH (BATTERY MASTER SWITCH)
999
POSITIVE CABLE FROM BATTERY TO MASTER SWITCH
999
NEG. CABLE SWITCH TO SUBSTRUCTURE
999
999
POSITIVE CABLE FROM STARTING SWITCH TO STARTING CHANGE-OVER SWITCH
999
999
NEG. CABLE FROM MASTER SWITCH TO GROUND
999
