Поз.
Артикул
Описание
5
NUT , Replaced By: N304032010002
8
LOCK WASHER , Replaced By: N912004010102
11
INTERMEDIATE PIECE STARTING MOTOR INTERMEDIATE FLANGE
11
INTERMEDIATE PIECE STARTING MOTOR
14
SCREW ALTERNATOR MOUNTING
17
WASHER , Replaced By: N000433010510
17
WASHER SUPPORT TO ALTERNATOR TO 352 150 09 73
20
NUT AIR CLEANER ELEMENT
26
BRACKET ALTERNATOR
26
BRACKET ALTERNATOR
26
SUPPORT , NOT USED, Replaced By: A3761507173
29
BUSHING
29
BUSHING
29
BUSHINGTO 355 150 03 72,366 150 13 72
32
CLAMPING BOLT CLAMPING BOLT TO ALTERNATOR
32
CLAMPING BOLT CLAMPING BOLT TO ALTERNATOR
35
BUSHINGTO 355 150 03 72,366 150 13 72
35
BUSHING
50
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
53
NUT TIGHTENER PULLEY TO LEVER
59
SCREW PEDAL BEARING BRACKET TO SIDE MEMBER,734154
62
SCREW CLAMPING BOLT TO ALTERNATOR
62
SCREW , Replaced By: N000961012184
65
WASHER SUPPORT TO FRAME,D 127794
68
NUT FUEL TANK TO SUPPORT
74
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
77
SPRING WASHER CABLE TO ALTERNATOR
