Поз.
Артикул
Описание
5
FUEL TANK
10
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
12
SENDER UNIT ,4 312465
12
SENDER UNIT ,4 261141, Replaced By: A0045424617, +001A0004710235, +002A3054760126, +001A3879900078
12
SENDER UNIT ,4 261142-4 312464, Replaced By: A0045424617, +001A3054760126, +001A3879900078
12
SENDER UNIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 656938, Replaced By: A0055423417
12
SENDER UNIT , Replaced By: A0085427717
13
EXPANSION PLUG
14
FUEL STRAINER FUEL TANK,K 169122
14
FUEL STRAINER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 261141, Replaced By: A0004710235
20
SEAL RING FUEL STRAINER SCREEN
20
SEAL RING FUEL LINE TO FEED PUMP
22
FITTING FUEL LINE TO FUEL TANK,4 493047
22
FITTING
22
SCREW PLUG , Replaced By: N007604014110
22
SCREW PLUG FUEL TANK
30
FILLER CAP , Replaced By: A0004700305
30
FILLER CAP , Replaced By: A0004717930
30
FILLER CAP , Replaced By: A0004700305
30
FILLER CAP , Replaced By: A0004700305
30
FILLER CAP
31
SEAL RING
31
SEAL RING , Replaced By: A3049970340
32
CHAIN FILLER CAP
40
SUPPORT ,4 690101, Replaced By: A3834701442, +001A6174700440, +002A3859900551
40
SUPPORT ,4 690102-4 829901 TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3834701842, +002N000961014097, +002N912004014100
40
SUPPORT ,4 829902
45
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
45
LOCK WASHER FITTING TO BRACKET
47
SCREW CONSOLE TO SIDE MEMBER
47
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
47
SCREW , Replaced By: N308676014020
49
WASHER , Replaced By: A3379900440
49
WASHER TRAILER COUPLING TO REAR CROSS MEMBER
50
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
55
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
60
STRAP FUEL TANK TO SUPPORT
60
STRAP FUEL TANK TO SUPPORT,5 149420
60
STRAP ,4 6901025 149419, Replaced By: A6174700440, +001N000934012022
62
PIN STRAP TO SUPPORT,4 492432
65
WASHER STRAP TO SUPPORT
67
NUT STRAP TO SUPPORT,5 149419
67
NUT STRAP TO SUPPORT
75
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
75
HOSE FROM WARNING INDICATOR TO AIR CLEANER, ORDER BY THE METER
79
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
95
HOSE LEAK LINE, ORDER BY THE METER
100
BANJO UNION FEED
102
SLEEVE LEAK LINE
102
SLEEVE FEED
102
BUSHING , Replaced By: N915062004000
102
BUSHING , Replaced By: N915062004000
102
CONNECTOR RIGHT,177-LITER
105
ELBOW FITTING RETURN
107
FITTING RETURN
108
UNION NUT
115
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
120
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
120
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
120
CLAMP , Replaced By: N000000000665
125
LOOM TIE LINE MOUNTING
125
LOOM TIE LINE MOUNTING 280 MM
130
GROMMET FUEL LINE THRU FRAME SIDE MEMBER,4 367061
130
GROMMET LINE PASSAGE AT SIDE MEMBER
145
SEAL RING FUEL LINE TO FEED PUMP
150
HOLLOW SCREW , Replaced By: N915036010108
150
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
999
CLIP LEAK LINE
999
HOSE LEAK LINE
999
FUEL TANK , Replaced By: A3834701101, +001N007603014302, +001N007604014106
999
COTTER PINROCKINGER TYP 260 G140
