Поз.
Артикул
Описание
163
SCREW PLUG SOCKET TO FRAME
163
SCREW BRACKET TO FRONT PANEL, 032,033,040,041,132,133,140,141 FROM CAB 1500001
164
WASHER TRAILER PLUG SOCKET TO BRACKET
166
LOCK WASHER RAIL TO BATTERY SUPPORT
166
LOCK WASHER TAIL LAMP TO BRACKET
168
SCREW PLUG SOCKET TO FRAME
168
SCREW BRACKET TO SIDE MEMBER
170
WASHER TRAILER PLUG SOCKET TO BRACKET
170
WASHER GROUND CABLE
170
WASHER GROUND CABLE
173
LOCK WASHER , Replaced By: N912004010102
173
LOCK WASHER DELIVERY AND SUCTION LINES TO PIPE CLAMP,1401150112256208
175
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
175
NUT LEVER TO SHIFTING SHAFT
200
AIR CLEANER , Replaced By: A3440947202
200
AIR CLEANER , 032,033,040,041,132,133,140,141 FROM CAB 1500001 INAPPLICABLE TO SUPERCHARGING SYSTEM 030-041 UP TO IDENT NO.: 679207
205
FILTER ELEMENT , Replaced By: A0020941304
205
FILTER ELEMENT , 032,033,040,041,132,133,140,141 FROM CAB 1500001 INAPPLICABLE TO SUPERCHARGING SYSTEM 030-041 UP TO IDENT NO.: 679207
209
GASKET OUTSIDE
209
GASKET OUTSIDE TO 005 094 17 02, 030-041 UP TO IDENT NO.: 679207
214
GASKET INSIDE
214
GASKET OIL BATH AIR CLEANER, 705598
219
FILTER BOWLTO 005 094 17 02, 032,033,040,041,132,133,140,141 FROM CAB 1500001 030-041 UP TO IDENT NO.: 679207
222
FASTENERTO 376 090 96 01
222
FASTENER , Replaced By: A0010940055
226
BRACKET , 352.00/1,353,358 FROM CHASSIS 676465 ALSO INSTALLED ON 500001-599999,TYP 360 FROM CHASSIS 676465
240
AIR CLEANER , Replaced By: A3440947302
240
AIR CLEANER
244
LOOM TIE. CLAMP
244
LOOM TIE. CLAMP AS REQUIRED
248
HOSE
251
CLAMP. LOOM TIE90-110
999
VACUUM BOXTO 345 094 85 02
999
VALVETO 376 090 96 01
999
BOTTOM PARTITION
999
SCREW CABLE CONNECTOR TO BRACKET
999
ADAPTER FITTINGTO 345 094 78 02,345 094 79 02
999
THREADED NIPPLETO 345 094 78 02,345 094 79 02
999
LOCKTO 345 094 78 02,308 094 76 02
999
WASHER FELT
999
NUTTO 345 094 78 02,345 094 79 02
999
NUTTO 345 094 79 02,345 094 77 02
999
NUT
999
BRACKETTO 345 094 78 02,345 094 79 02,77 02
999
SEAL RINGTO 345 094 78 02,345 094 79 02
999
SEPARATORTO 374 094 00 02
999
CYCLONE PRE-FILTER BOWLTO 345 094 77 02,345 094 78 02
999
SCREW
999
VACUUM BOXTO 345 094 78 02,345 094 79 02
999
SCOOPTO 345 094 77 02
999
FILTER BOWLTO 345 094 78 02,345 094 79 02
999
FILTER BOWLTO 345 094 80 02,81 02,85 02
999
NUTTO 345 094 81 02,80 02,85 02
999
THREADED UNIONTO 345 094 81 02,80 02,85 02
999
FILTER ELEMENT
999
GASKETTO 345 094 78 02
999
FILTER BOWL ,1400510214005103-1500000
999
BRACKET , 032,033,040,041 UP TO CAB 1500000
999
PIPE ELBOW , Replaced By: A3445280807
999
NUT
999
FILTER BOWLTO 376 090 96 01CICLONIZADOR
999
COVERTO 345 094 71 02,345 094 80 02
999
FILTER ELEMENTTO 376 090 82 04
999
VACUUM BOXTO 345 094 80 02,78 02,81 02
