Поз.
Артикул
Описание
5
TANK POWER STEERING
8
OIL DIPSTICK ,D 523393
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER ELEMENT ,D 441028D 523393
25
STRAP OIL TANK
26
SCREW BRACKET TO SIDE MEMBER
35
SCREW , Replaced By: N304017010040
35
SCREW , Replaced By: N304017010040
41
HOSE (SUCTION LINE),FROM OIL TANK TO PUMP,D 117338 ORDER BY THE METER
45
LINE FROM HOSE TO POWER STEERING PUMP
47
UNION NUT LINE CONNECTION, Replaced By: N000000006243
49
GLAND , Replaced By: A0019901267
50
BANJO UNION
51
HOLLOW SCREW AIR COMPRESSOR,CONNECTION: "2"
52
SEAL RING ENGINE AIR COMPRESSOR,CONNECTION: "20"
53
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
66
LINE FROM OIL PUMP TO HIGH PRESSURE HOSE
71
UNION NUT LINE CONNECTION, Replaced By: N000000006239
74
GLAND , Replaced By: A0019901967
75
BANJO UNION
76
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
78
SEAL RINGTO 006 997 00 72
79
HOSE DELIVERY LINE TO PUMP
79
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
79
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
80
LINE FROM HIGH PRESSURE HOSE TO STEERING
83
UNION NUT LINE CONNECTION, Replaced By: N000000006239
86
GLAND , Replaced By: A0019901967
87
BANJO UNION
90
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
92
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
101
LINE FROM RUBBER HOSE TO RUBBER HOSE,D 168595
101
LINE FROM STEERING TO OIL TANK,D 168594
101
LINE FROM STEERING TO HOSE,D 168595
108
BANJO UNION COMPRESSED AIR LINE TO AIR COMPRESSOR
110
HOSE HIGH PRESSURE
110
HOSE
113
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
113
CLAMP , Replaced By: N000000000667
113
CLAMP HOSE TO HEATING PIPE
113
LOOM TIE. CLAMP HOSE TO FLANGE AND TO VALVE
113
LOOM TIE HOSE TO HEATING PIPE
177
SCREW ELECTRICAL COMPARTMENT
185
WASHER PLUG SOCKET TO BRACKET
191
NUT PUMP TO BRACKET
197
CLAMP DELIVERY AND SUCTION LINES TO FRAME
197
CLAMP LINE MOUNTING
197
CLAMP OIL DIPSTICK TO RADIATOR
197
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
STEERING SHAFT BOTTOM 715-780MM, NOT USED
