Поз.
Артикул
Описание
6
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
6
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
6
BRAKE VALVE SERVICE BRAKE WABCO
6
BRAKE VALVE SERVICE BRAKE KNORR
8
LOCKTO 345 431 70 05
11
SPRINGTO 345 431 70 05
14
SPRINGTO 345 431 70 05
17
SPRINGTO 345 431 71 05
20
PISTONTO 345 431 71 05
20
PISTONTO 345 431 70 05
23
LOCK RING PLANETARY CARRIER
23
LOCK RING
23
LOCK RINGTO 345 431 71 05
23
LOCK RINGTO 345 431 71 05
24
GASKET KIT TWO-CIRCUIT BRAKE VALVE TO 002 431 87 05
25
REPAIR KIT SMALL SCOPE TO 695 431 74 04
25
REPAIR KIT LARGE SCOPE TO 695 431 71 04
26
REPAIR KIT , Replaced By: A0014300460
26
REPAIR KIT LARGE SCOPE TO 345 431 70 05
26
REPAIR KIT SMALL SCOPE TO 345 431 71 05
26
REPAIR KIT SMALL SCOPE TO 345 431 70 05
29
GASKET BRAKE SHOE WITH LINING
32
NUT BATTERY CASE
35
SPRING WASHER BRAKE SHOE WITH LINING
38
ROD FROM FITTING TO CLUTCH BOOSTER
41
YOKE
44
NUT FUEL TANK TO SUPPORT
44
NUT FUEL TANK TO SUPPORT
47
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
50
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
53
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
56
SWITCH STOP LIGHT
56
SWITCH STOP LIGHT
56
SWITCH , Replaced By: A6965450009
56
SWITCH , Replaced By: A6935457309
56
SWITCH , Replaced By: A6965450009
56
SWITCH EXHAUST BRAKE,K 251255
56
SWITCH TWO-CIRCUIT BRAKE VALVE
59
SCREW PLUG
62
SEAL RINGTO 006 997 00 72
63
SCREW. UNION SCREW LINE CONNECTION
64
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
65
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
68
VALVE (QUICK BREATHER VALVE) WABCO
68
VALVE QUICK-RELEASE VALVE KNORR
68
VALVE (QUICK BREATHER VALVE) VARGA
74
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
74
REPAIR KITTO A 364 429 70 44
77
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
80
SEAL RINGTO 006 997 00 72
83
SCREW PLUG AT TANK
83
SCREW PLUG
86
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
86
ELBOW FITTING , Replaced By: A3849907071
89
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
92
THRUST RING LOCKING VALVE
92
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
92
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
98
BRACKET QUICK-RELEASE VALVE
101
SCREW BRACKET TO INTAKE MANIFOLD
104
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
107
VALVE (RELAY VALVE) KNORR
107
VALVE (RELAY VALVE)
107
VALVE (RELAY VALVE) WABCO
107
VALVE (RELAY VALVE),REAR AXLE
108
SCREW. UNION SCREW LINE CONNECTION
108
SCREW. UNION SCREW LINE CONNECTION
109
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
109
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
110
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
110
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
111
SCREW. UNION SCREW , Replaced By: A0009973734
111
SCREW. UNION SCREW , Replaced By: A0009973734
112
LOCK , Replaced By: A0009945448
112
LOCK , Replaced By: A0009945448
113
SEAL RING , Replaced By: A0009940747
113
SEAL RING , Replaced By: A0009940747
114
REPAIR KIT SMALL SCOPE TO 001 429 68 44
114
REPAIR KITWABCO
114
REPAIR KITTO 003 429 30 44
114
REPAIR KITTO 003 429 30 44,KNORR
114
REPAIR KITTO 386 429 70 44
114
REPAIR KIT. VALVE REPAIR KIT TO 695 429 71 44
115
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
116
SEAL RING LINE CONNECTION
119
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
122
SEAL RINGTO 006 997 00 72
125
ELBOW FITTING RELAY VALVE,CONNECTION: "20"
128
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
131
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
131
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
131
THRUST RING LOCKING VALVE
134
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
137
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
137
SCREW PLUG
140
SEAL RINGTO 006 997 00 72
140
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
143
VALVE TWO-WAY
143
VALVE (TRAILER CONTROL VALVE) "KNORR"
143
VALVE (TRAILER CONTROL VALVE) "KNORR"
149
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
152
SEAL RINGTO 006 997 00 72
155
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
158
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
158
SWITCH
161
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
164
THRUST RING LOCKING VALVE
164
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
164
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
167
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
170
BRACKET (RELAY VALVE)
170
BRACKET REAR AXLE RELAY VALVE
171
BRACKET RELAY VALVE
173
WASHER TRAILER PLUG SOCKET TO BRACKET
176
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
176
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
179
SCREW , Replaced By: N304017010002
182
NUT BRACKET TO SIDE MEMBER,XB209706
185
DISTRIBUTOR ENGINE SHUT-OFF,5 766894
188
PLUG DISTRIBUTOR,CONNECTIONS: "03,04,05",TO M 16,5 766894
191
SCREW DISTRIBUTOR TO CROSS MEMBER,D 132997
194
WASHER PLUG SOCKET TO BRACKET
194
WASHER , Replaced By: N009021006208
197
NUT , Replaced By: N910113006001
999
DIAPHRAGM ,058011
999
SEAL RING ,058011
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
REPAIR KIT , Replaced By: A0005862842
