Поз.
Артикул
Описание
5
9
9
9
13
21
25
28
BRAKE HOSE COMPRESSED AIR HOSE
32
CONNECTOR AT AIR COMPRESSOR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
35
SEAL RING ENGINE AIR COMPRESSOR,CONNECTION: "20"
38
CONNECTION FITTING , Replaced By: N003902018002
41
BRACKET , Replaced By: A3812950440
41
BRACKET POS. CABLE,XB209706
45
CLAMP LINE MOUNTING
48
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
52
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
52
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
55
NUT BRACKET TO FIRE WALL
