Поз.
Артикул
Описание
5
8
11
BUSHING
11
BUSHING
17
20
38
SLIDING BLOCK AT SPRING LEAF NO.270X90X13 MM
41
SLIDING BLOCK BETWEEN THE SPRING LEAVES
44
SCREW
47
HEXAGON NUT M6
50
53
56
56
59
STAY REAR SPRING TO REAR AXLE
62
HEXAGON HEAD BOLT. SCREW LOCK SPRING TO CROSS MEMBER M14X1.5X30
65
PLATE REAR SPRING TO REAR AXLE, NO.7390 IIIII I
68
71
WASHER FRONT SPRINGS TO FRONT AXLE
71
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
74
NUT STABILIZER TO FRONT AXLE
77
SHACKLE REAR-SPRING REAR BRACKET
80
SHACKLE PIN REAR SPRING TO SPRING SHACKLE AND TO SPRING FRONT AND REAR BRACKETS
80
SHACKLE PIN
83
GREASE NIPPLE PROTECTIVE TUBE
86
WASHER AS REQUIRED 4.0 MM
86
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
86
WASHER AS REQUIRED 4.2 MM
86
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
89
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
92
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
98
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
101
101
107
SCREW STOP BUFFER TO FRAME M 10X30
113
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
130
130
130
PLATE RIGHT
130
PLATE LEFT
133
133
140
SLEEVE BOTTOM
150
SPRING BOLTM 12X135
160
NUT , Replaced By: N910113012005
