Поз.
Артикул
Описание
5
FUEL TANK
5
FUEL TANK , Replaced By: A3834701101, +001N007603014302, +001N007604014106
11
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
14
SENDER UNIT ,4 312465
14
SENDER UNIT , Replaced By: A0085427717
14
SENDER UNIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 656938, Replaced By: A0055423417
22
FUEL STRAINER FUEL TANK,K 169122
28
SEAL RING FUEL STRAINER SCREEN
34
FITTING FUEL LINE TO FUEL TANK,4 493047
34
FITTING
43
FILLER CAP , Replaced By: A0004700305
43
FILLER CAP
43
FILLER CAP , Replaced By: A0004700305
43
FILLER CAP , Replaced By: A0004717930
43
FILLER CAP , Replaced By: A0004700305
48
SEAL RING
48
SEAL RING , Replaced By: A3049970340
53
CHAIN FILLER CAP
59
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
64
SUPPORT ,4 829902
64
SUPPORT ,4 690102-4 829901 TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3834701842, +002N000961014097, +002N912004014100
64
SUPPORT ,4 690101, Replaced By: A3834701442, +001A6174700440, +002A3859900551
69
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
69
SCREW , Replaced By: N308676014020
69
SCREW CONSOLE TO SIDE MEMBER
76
LOCK WASHER FITTING TO BRACKET
87
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
98
STRAP FUEL TANK TO SUPPORT,5 149420
98
STRAP ,4 6901025 149419, Replaced By: A6174700440, +001N000934012022
98
STRAP FUEL TANK TO SUPPORT
107
WASHER STRAP TO SUPPORT
112
PIN STRAP TO SUPPORT
122
NUT STRAP TO SUPPORT
128
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
130
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
143
SLEEVE FEED
143
CONNECTOR RIGHT,177-LITER
159
CLIP LEAK LINE
164
HOSE LEAK LINE
174
BRACKET FUEL LINE TO BELL HOUSING
174
BRACKET , Replaced By: A6454310740
179
BRACKET FUEL LINES TO TRANSMISSION
179
BRACKET , Replaced By: A6205240340
186
LOOM TIE LINE MOUNTING
192
GROMMET LINE PASSAGE AT SIDE MEMBER
197
SEAL RING FUEL LINE TO FEED PUMP
203
HOLLOW SCREW FUEL LINE TO FEED PUMP
203
HOLLOW SCREW , Replaced By: N915036010108
203
HOLLOW SCREW , Replaced By: N915036010100
999
EXPANSION PLUG
999
FITTING RETURN
999
LOOM TIE LINE MOUNTING 280 MM
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
BRACKET PULL ROD TO SUPPORT,5 352764 TO BE ADAPTED DURING ASSEMBLY
999
BRACKET , Replaced By: A3184924841
999
GROMMET FUEL LINE THRU FRAME SIDE MEMBER,4 367061
999
BANJO UNION FEED
999
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
999
COTTER PINROCKINGER TYP 260 G140
999
SCREW , Replaced By: N304017008034
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW PLUG , Replaced By: N007604014110
999
SCREW PLUG FUEL TANK
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
UNION NUT FUEL HOSE
999
BANJO UNION , Replaced By: N000000000363
999
CLAMP , Replaced By: N000000000665
