Поз.
Артикул
Описание
6
HOSE LEAK LINE, ORDER BY THE METER
12
PLASTIC PIPE RISING PIPE 4X6 MM
12
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
18
GLAND , Replaced By: A0019901667
18
SEAL CONE
24
SLEEVE LEAK LINE
30
UNION NUT
36
FITTING LINE CONNECTION TO FIRE WALL,5 726664
42
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
48
GLAND LINE CONNECTION
54
SLEEVE LINE CONNECTION
60
UNION NUT LINE CONNECTION
66
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
72
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
78
BANJO UNION HEATING CONNECTION,K 169122
84
HOLLOW SCREW HEATING CONNECTION
90
HOLLOW SCREW LINE CONNECTION
96
SEAL RING LINE CONNECTION
102
FITTING
108
GROMMET FUEL LINE THRU FRAME SIDE MEMBER 38/30 MM
114
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
114
HOSE , Replaced By: A0009872827
120
GLAND , Replaced By: A0019901967
120
SEAL CONE LINE CONNECTION
126
SLEEVE LINE CONNECTION
132
UNION NUT LINE CONNECTION
132
UNION NUT LINE CONNECTION, Replaced By: N000000006239
138
BANJO UNION , Replaced By: N915052009009
138
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
144
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
150
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
156
FITTING BULKHEAD FITTING
162
T-FITTING
168
NUT BRACKET TO SIDE MEMBER
174
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
180
GLAND LINE CONNECTION
186
UNION NUT LINE CONNECTION
186
UNION NUT BUTT SCREW CONNECTION
192
CLAMP LINE MOUNTING
198
SCREW CLAMP TO BRACKET
198
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
204
NUT , Replaced By: N913004006001
204
NUT PUMP TO BRACKET
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
FITTING (PARTS KIT),LINE RUPTURE
999
PLUG
